socket. From there, send a line from
the MAIN OUT of a mixer (such as a
XENYX 1202FX) to a power amplifi er
(like the EUROPOWER EP2000).
Finally, attach a B212XL or B215XL
to each of the amp’s outputs. These
loudspeakers have inputs for both
professional speaker cable and ¼" cable. Because these
loudspeakers have two parallel
inputs, you can connect up to two
of them to any channel on a power
amp.
But these loudspeakers don’t
have to be confi ned to an upright
position. Just lay them on their sides
272.00 mm [10.7086 in]
348.80 mm [13.7322]
549.64 mm [21.6394]
336.00 mm [13.2283 in]
436.00 mm [17.1653 in]
695.25 mm [27.3719 in]
B212XL B215XL
Continued on next page
Parallel ¼"
loudspeaker inputs.
Professional
speaker inputs
wired in parallel.
B212XL / B215XL
B212XL-WH/
B215XL-WH
12"/15" 2-way
Passive Speakers
