EXPLODED VIEWS AND PARTS LISTS
3
EXPLODED VIEW - PARTS LIST
Item Part #
Description
1
J197129GS
KIT, Frame
2
194150GS
KIT, Vibration Mount 45°
3
*
WASHER, M8 Lock
4
190220GS
HOUSING, Engine Adapter
5
*
NUT, Hex M8 - 1.25
6
NSP
ASSY., Alternator (see page 5)
7
*
TPHMS, M8 - 1.25 x 35
8
96796GS
WASHER, M8 Flat
9
67989GS
NUT, M8 Flange Serrated
10
190274BGS
SBHCS, 3/8-16 x 1.0 Lg
11
47480GS
HHCS, 5/16-24 x 7
12
*
HHCS, M8 1.25 x 25
14
189009GS
BRACKET, Muffler
15
695398
GASKET, Exhaust
16
*
HCS, M6 1.0 x 12
17
189008GS
MUFFLER
18
*
SHCS, 5/16 - 18 x 7/8"
19
83083GS
SCREEN, Spark Arrest
20
B4986GS
DECAL, Ground, Green
21
194153GS
KIT, Vibration Mount
22
86494GS
SCREW, Wing, M6 1 x 16
23
195094GS
SCREW, 10-16 x .68, Self Drill
24
192793GS
SHIELD, Heat
25
191190GS
CAP
26
74908GS
SCREW, M5-0.8 x 10 Taptite
28
*
WASHER, Flat 1/2
29
94929GS
SCREW, Hex Wash HD
30
226846
BRACKET, Oil Fill Tube
31
196830GS
DECAL, Hot Muffler
34
195422GS
COVER, RBC, Plastic w/Cap
35
199838GS
KIT, Fuel Hose w/clamps (cut to fit)
37
192376GS
SCREW, 12 - 24 x 1/2 THD Forming
40
192310GS
KIT, Vibe Mount
41
192980GS
KIT, Valve Tank
Item Part #
Description
44
196181GS
ASSY., Tank, Fuel, 5 Gallon (includes
items 41, 50, 51 & 52)
45
189420GS
CAP, Fuel Gauge
48
195373GS
WIRE, Ground
49
203650GS
KIT, Wheel
50
188333GS
DECAL, Fuel Tank
51
194799GS
DECAL, Danger
52
189235GS
DECAL, Start Instructions
53
192050GS
E-RING
55
197798GS
DECAL, Shut-Off, Fuel
56
J194907GS
HANDLE
57
189456GS
KIT, Handle Fastening
58
197641GS
ASSY, Control Panel
59
*
NUT, Palnut 3/16"
60
189117GS
QUICK CONNECT, Fuel, 1/4 Barb
61
192695GS
QUICK CONNECT, Fuel, 1/4 Barb
62
201079GS
DECAL, CO Warning
63
189114GS
KNOB, Fuel Tank Hold Down
72
192480GS
DECAL, Warning, Fuel Line
Disconnect
900 §
ENGINE
Parts Not Illustrated
BB3061GS
OIL BOTTLE
197474GS
CORDSET, Storm
MS3430
MANUAL, Engine
199718GS
MANUAL, Operator’s
202180GS
DECAL, Family, CA EVP
186208GS
STABILIZER, 1oz Tube
197581GS
TRAY, Overflow, Fuel
198419GS
KIT, Decals Srv
* - Items without part numbers are common fasteners and
are available at your local hardware store.
§ - Contact Engine Manufacturer
