Briggs & Stratton Power Products Home Generator System
Owners Manual
UNIT PARTS LIST
Item Part #
Qty. Description
1
NSP
1
ENGINE
2
22259GS
6
NUT
3
22129GS
16 LOCKWASHER
4
48031JGS
1
CLIP, Hoseband
5
92134GS
1
FILTER, Oil
6
H186285GS
1
PAN, Engine Mounting
7
186071GS
1
VALVE, Oil Drain
8
186430GS
1
HOSE, Oil Drain
9
25017GS
2
CAPSCREW, Hex Head
10 22237GS
14 LOCKWASHER
11 38353GS
4
MOUNTS,Vibration
12 H185972GS
1
BASE, Mount
13 22531GS
2
CAPSCREW, Hex Head
14 92609GS
2
MOUNTS,Vibration
15 29745GS
2
CAPSCREW, Hex Head
16 22241GS
6
NUT
17 51754GS
1
CAPSCREW, Hex Head
18 187032GS
1
WASHER, Ext., Shakeproof
19 H185957GS
1
SUPPORT, Alt.
20 22127GS
3
NUT
21 186152GS
1
HOSE, Gas Regulator to Engine
22 57822GS
2
CLAMP, Hose
23 H185966GS
1
BULKHEAD, Alternator Side
24 186640GS
1
DECAL, Outdoor Use Only
25 H189952GS
1
STRAP, Battery Hold Down
26 B4300GS
2
SWAGE BOLT
27 42907GS
6
CAPSCREW, Hex Head
28 188574GS
1
CABLE, Battery Positive
29 188443GS
1
BATTERY, 33AH
30 22131GS
2
WASHER, Flat
31 22145GS
2
WASHER, Flat
32 188573GS
1
CABLE, Battery Negative
33 186070GS
4
WASHER, Fiber
34 39253GS
2
CAPSCREW, Hex Head
35 186148GS
1
HOSE, Gas - regulator
36 186151GS
1
ELBOW, Brass
37 45757GS
2
CAPSCREW, Hex Head
38 190866GS
1
REGULATOR, Gas Fuel
39 186150GS
1
ELBOW, Brass
40 B4773GS
1
SOLENOID, Gas Fuel
41 H185961GS
1
CORNER, Alt. Air Inlet, Left
42 26850GS
3
WASHER, Ext. Shakeproof
43 B4300GS
2
BOLT SWAG
44 B4769GS
1
CONTACTOR, Starter
45 186375GS
1
CLAMP, Hose
46 185955GS
4
STUD, Muffler Mount
47 187049GS
1
PLUG, Dome
48 49813GS
4
NUT
49 22097GS
7
LOCKWASHER
Item Part #
Qty. Description
50 22473GS
4
FLAT WASHER
51 H186125GS
4
BRACKET, Muffler
52 H186030GS
1
BASE, Muffler Box
53 56893GS
16 CRIMPTITE
54 22264GS
2
LOCKWASHER
55 186790BGS
1
WIRE, Ground
56 67897GS
2
MANIFOLD, Gasket
57 185900GS
1
MANIFOLD, Exhaust
58 186062GS
1
GASKET, Manifold, Muffler
59 86307GS
2
CAPSCREW, Hex Head
60 B4260GS
1
DISK, Air Blocker
61 186242GS
2
MACHINE SCREW, Phllps Pn Hd
62 186205GS
1
SWITCH,Thermodisk Oil Temp.
63 27772GS
2
LOCKWASHER, Int.Tooth
64 186206GS
1
PLATE, Oil Temp Switch
65 B4268GS
1
ALTERNATOR, Sincro
66 22511GS
4
CAPSCREW, Hex Head
67 H186320GS
1
DEFLECTOR, 45° Muffler Box
68 H186038GS
1
BOX, Muffler
69 185894GS
1
MUFFLER, with Brackets
70 22471GS
2
NUT
71 185939CGS
1
CABLE, Starter
72 23152GS
2
CAPSCREW, Hex Head
73 27482GS
1
WASHER, Ext. Shakeproof
74 186790CGS
1
WIRE, Ground
75 186640GS
1
DECAL, Oil Drain
76 B4986GS
1
DECAL, Ground, Green
77 186551GS
1
INSULATION, Fuel Hose
78 26915GS
1
NIPPLE
79 69397GS
4
BOLT, Manifold
80 45771GS
8
NUT
81 187277GS
1
SCREEN, Spark Arrester w/
screws
82 H189951GS
1
TRAY, Battery Support
83 96924GS
2
J-BOLT
84 49820GS
2
NUT, Locking Hex
85 59637GS
1
TAPTITE
86 96137GS
1
PLUG
87 189295GS
1
FLAT WASHER
88 A6344GS
1
FITTING, Barbed, 90°
89 189294GS
1
E-RING
90 52857GS
2
NUT, Flange Locking
91 B3518GS
1
CAP, Funnel, Oil Bottle
92 190838GS
1
MANUAL, Install
93 190839GS
1
MANUAL, Owners
94 B5053GS
1
ASSEMBLY, Key
95 B5478GS
1
PAINT,Touch-Up
96 190824GS
1
HOSE, Flex
97 191041GS
1
KIT, LED Remote
