6
Figure 1. Front and Rear Panels
Item Description
LEDs Power, WLAN, WAN and LAN port status indicators.
(See “LED Indicators” on page 1.)
LAN
Fast Ethernet ports (RJ-45). Connect devices (such as a PC,
Ports hub or switch) on your local area network to these ports.
Reset
Use this button to reset the power and restore the default
Button factory settings.
WAN
WAN port (RJ-45). Connect your cable modem, DSL modem,
Port or an Ethernet router to this port.
Power Connect the included power adapter to this inlet.
Inlet Warning: Using the wrong type of power adapter may
damage your Wireless Router.
