Page 3
3500W Portable Generator
3
EXPLODED VIEW - PARTS LIST
Item Part #
Description
1
M194779GS
CRADLE
2
194150GS
KIT, Vibration Mount
3
*
TPHMS, M8 1.25 x 35
4
186058AGS
HOUSING, Engine Adapter
5
NSP
ASSY, Alternator (see page 4)
6
*
NUT, Hex, M8 - 1.25
7
67989GS
NUT, M8 Flange Serrated
8
96796GS
WASHER, 8.4 x 22.2 x 3
9
*
WASHER, Lock M8
10
86307GS
HHCS, 5/16-24 x 3/4, SEMS
11
24823GS
HHCS, 5/16-24 x 7-7/8”
12
*
HHCS, M8 - 1.25 x 25
14
191785GS
BRACKET, Muffler
15
697815
GASKET, Exhaust
16
*
HHCS, M6 1.0 x 12 with Lock
Washer
17
188301GS
MUFFLER
18
*
SHCS, M6 - 1.0 x 20
19
83083GS
SCREEN, Spark Arrest
20
B4986GS
DECAL, Ground
22
86494GS
SCREW, Wing M6 - 1.0 x 16
21
194153GS
KIT, Vibration Mount
24
191790GS
SHIELD, Heat
25
191190GS
CAP
26
74908GS
TAPTITE, M5-0.8 x 10
31
196830GS
DECAL, Caution Exhaust
Item Part #
Description
34
195422GS
COVER, RBC with Cap
35
195207GS
KIT, Fuel Hose with Clamp
37
B2153GS
HHCS, 12 - 14 x 7/8" Self Driller
40
194398GS
KIT, Fuel Tank Hardware
41
192980GS
KIT, Valve, Tank
44
193645GS
ASSY., Tank, Fuel Service (includes
Items 41, 50, 51, 52 & 53)
45
200095GS
CAP, Fuel
48
195373GS
WIRE, Ground
50
188333GS
DECAL, Fuel Level
51
194799GS
DECAL, Danger
52
189235GS
DECAL, Operating Instructions
53
202997GS
DECAL, CO Warning
55
197798GS
DECAL, Fuel Shut Off
58
191743AGS
ASSY, Control Panel
59
* (189164)
NUT, Palnut, 3/16"
900 § (203492)
ENGINE
Parts Not Illustrated
203476GS
MANUAL, Operator’s
BB3061BGS
OIL BOTTLE
195576GS
KIT, Decals, Service
§ - Contact Engine Manufacturer
* - Items without part numbers are common fasteners and
are available at your local hardware store.
