-3-
STAND ASSEMBLY HARDWARE
Item Qty. Part Description
G 6 10mm x 100mm Hex Head Bolts
H 2 10mm x 50 mm Hex Head Bolts
I 6 8mm x 50 mm Phillips Head Screws
J 22 10mm Flat Washers
K 2 10mm Star Washers
L 8 10mm Lock Nuts
M 6 8mm Lock Nuts*
N 4 6mm x 75mm Hex Head Bolt (4000 Table Saw)
O 4 6mm x 90mm Hex Head Bolt (4100 Table Saw)
P 8 6mm Flat Washer
Q 4 6mm Lock Nuts
G H I
J
K
L
M
N
O
P Q
*Note: There are two (2) 8mm x 50mm Phillips head screws and two (2) 8mm lock nuts to be
used only when attaching other branded table saws to the Bosch TS2000 stand. See page 7
for instructions.
