Electrical and operating controls - model cez – Bunn CEZ User Manual
Page 19
ITEM
PART NO.
QTY.
DESCRIPTION
19
1
12921.0000
1
Switch Blank, BLK
2
12920.0000
3
Switch, ON/OFF
3
01063.0000
1
Switch, MOMENTARY START
4
29327.0000
1
Probe Kit, Temperature and Dry Plug
5
07412.1001
1
Probe, Liquid Level
01501.0000
1
Washer, Flat .164" I.D. x .375" O.D.
20203.0100
1
Lockwasher, Internal-tooth #8
00908.0000
1
Nut, Hex #8-32
6
- - - - - - - -
1
Dispense Valve (See DISPENSE VALVE AND LINES)
7
13352.0008
1
Front End Cap
02301.0000
4
Screw, Pan-head #6-32 x .625"
00973.0000
4
Nut, KEPS #6-32
8
22289.0014
1
Decal, Control Panel
9
12517.0001
1
LED Kit (includes item 10)
10
03851.0000
2
Wire Nut, TAN 2-22AWG
11
29219.0000
1
Label, Switch (Brewers with three lower warmers)
29219.0001
1
Label, Switch (Brewers with one lower and two upper warmers)
12
- - - - - - - -
1
Solenoid (See SOLENOID AND LINES)
13
01309.0000
1
Screw, Grounding #10-32 x .50" (1 additional used on Black painted models)
14
01106.0000
1
Terminal Block, 2-pole
07038.0000
1
Terminal Block, 3-pole(MV models)
01317.0000
2
Screw #8-32 x .50"
15
28742.0000
1
PC Board, Control
02302.0000
4
Screw #6-32 x .875"
16
29081.0000
4
Spacer
17
01686.0000
1
Bushing, Strain Relief (15 AMP Brewers)
01685.0000
1
Bushing, Strain Relief (20 AMP Brewers)
18
01719.1000
1
Power Cord Assy (Includes item 19) (15 AMP Brewers only)
19
06064.0000
1
Label, Cord Warning
20
28177.0000
1
Terminal Block
01317.0000
2
Screw, Truss Head #8-32 x .50"
21
29673.0000
1
Bracket
22
28176.0000
1
Fuse Holder
02308.0000
2
Screw, Pan Head #8-32 x .375"
23
22012.0002
1
Fuse, 20 amp
24
00985.0000
1
Decal, Individual Circuit Info
The Following Items Are Not Illustrated
25
28749.0000
1
Wiring Harness, Main
29727.0000
1
Wiring Harness, Main(MV models)
26
24204.0001
1
Wiring Harness, Side Warmer
27
00617.0000
1
Cable Tie
28
29680.0000
1
Wiring Harness, Relay to Limit Thermostat
29
29681.0000
1
Lead, Tank Heater to Tank Heater
30
29682.0000
1
Wiring Harness, Upper Terminal Block to Heater
31
21016.0011
1
Lead, Elect. Grn/Yel 15.0"
32
21016.0027
2
Lead, Elect. Grn/Yel 26.0"
ELECTRICAL AND OPERATING CONTROLS - Model CEZ
MV models
MV models
29080 082503
Used on Black painted models only
