Page 3
BLACK BOX
®
3 of 3
09/28/2010
#26231
Item
Code
USB Director RS-232
Single-Port
IC1000A
2-Port
IC1001A
4-Port
IC135A
8-Port
IC1002A
If your PC doesn’t have a uSB port, order…
USB Card (PCI)
IC136C
You might also want to order…
Universal Serial Bus (USB) Cable
uSB01
What’s included
✦
(1) USB Director RS-232: Single-, 2-, 4-, or 8-Port
✦
(1) CD-ROM containing installation and utility drivers
✦
(1) 3.2-ft. (1-m) USB cable
✦
(1) Users’ manual
T e C h S P e C S
System Requirements — Pentium
®
class CPU with at least 16 MB RAM and
at least one available USB type A (downstream) port, running Windows 98,
SE, Me, CE, XP, or Windows 2000
Compliance —
EMI/RFI: CE (EN 55022, EN 55024)
Class B, FCC Part 15 Subpart B
Class B, IC Class/classe B;
Safety: UL
®
1950 (3rd. ed.),
CSA No. 950, IEC 950, EN 60950
Data Rate — Up to 230 kbps; Serial port(s) can be set to any data format,
flow control, or duplex setting the PC application supports
User Controls — Software drivers on included CD
Interface — Universal Serial Bus v1.1 (can be attached to a USB 2.0 host
but will operate at USB 1.1 data rates), EIA/TIA RS-232
Connectors —
All models: (1) USB Type B female (front-mounted on IC1001A,
rear-mounted on other models);
Rear-mounted DB9 male for
RS-232: IC1000A: (1);
IC1001A: (2);
IC135A: (4);
IC1002A: (8)
Indicators — IC1000A: None;
IC1001A, IC1002A, IC135A:
(1) Front-mounted tricolor LED
Temperature Tolerance — 32 to 131°F (0 to 55°C)
Humidity Tolerance — Up to 95% noncondensing
Power — USB-bus-powered, consumes less than 200 mA
at full operating speed
Size —
IC1000A: 0.8"H x 1.75"W x 3"D (2 x 4.4 x 7.6 cm);
DB9 thumbscrews protrude an additional 0.15" (0.4 cm) from the rear;
IC1001A, IC135A: 1"H x 7"W x 4"D
(2.5 x 17.8 x 10.2 cm);
IC1002A: 1.75"H x 7"W x 4.25"D
(4.4 x 17.8 x 10.8 cm)
Weight —
IC1000A: 1.6 oz. (45.4 g);
IC1001A: 12 oz. (340.2 g);
IC1002A, IC135A: 1 lb. (0.5 kg)
Universal Serial Bus (USB)
Universal Serial Bus is a royalty-free bus specification
developed by the leading manufacturers in the PC and
telephony industries to support plug-and-play peripheral
connections.
USB offers increased bandwidth and lower costs than
conventional I/O ports.
The USB bus is a daisychain consisting of USB hubs and
peripherals less than 16.4 ft. (5 m) apart. The USB daisychain
can support up to 127 devices. Instead of opening up the
CPU to insert new boards, make all connections outside the
case to the USB ports.
Because USB connections are hot-swappable, you can
attach or remove peripherals without shutting down your
computer.
technically Speaking
IC1002A: rear view
