Bosch GSH 16-28 User Manual
Page 2
Item
Quantity Order No.
Designation
Price group Page
2
1
1 614 220 188 FIELD \ 120V
47
1
3
1
1 614 011 118 ARMATURE \ 120V
51
1
4
1
1 617 200 112 ON-OFF SWITCH
34
1
5
1
1 614 461 033 POWER SUPPLY CORD \ USA/CDN 3,1m 3 x 2,08mm SJ0W
32
1
6
1
1 610 703 053 GROMMET \ Ш9,7-Ш12x90 MM
12
1
7
1
1 601 302 018 FASTENING CLAMP
11
1
9
1
1 611 110 D43 STICKER
13
1
15
1
1 616 610 102 FAN
27
1
21
1
1 613 103 004 LOCKING BOLT
40
1
22
1
1 618 045 024 RETAINING BRACKET
48
1
23
2
2 917 760 187 CLAMPING SLEEVE \ 8x55 DIN 1481
11
1
28
4
1 614 614 006 COMPRESSION SPRING
19
1
29
1
1 614 614 007 COMPRESSION SPRING
19
1
33
1
1 611 006 008 HOLDING PLATE
23
1
34
1
1 610 102 635 SUPPORTING DISC
26
1
37
1
1 615 500 380 FAN COVER
36
1
42
1
1 614 336 078 BRUSH HOLDER
38
1
42/2
2
1 614 336 017 BRUSH GUIDE
21
1
42/3
2
1 614 652 007 SPIRAL SPRING
15
1
42/6
2
1 611 390 005 CONNECTOR
11
1
42/8
4
2 912 401 412 SELF-TAPPING SCREW
11
1
43
1
1 610 508 054 SPACER
13
1
46
1
1 615 106 053 MOTOR HOUSING
33
1
47
1
1 618 000 029 BASE PLATE
27
1
48
1
1 615 500 383 HOUSING COVER
33
1
53
1
1 610 190 058 STOP DISC
24
1
54
1
1 610 312 003 SPACER TUBE
32
1
55
1
1 610 506 019 CONTROL BUSHING
34
1
56/58 1
1 610 500 023 RETAINING RING
19
1
56/70 1
1 612 001 042 CONNECTING ROD
30
1
56/71 1
1 613 101 012 PISTON PIN
17
1
60
1
1 616 317 079 CYLINDRICAL GEAR
45
1
61
1
1 616 317 080 CYLINDRICAL GEAR
47
1
72
1
1 616 110 037 ECCENTRIC SHAFT
48
1
75/74 2
1 613 060 049 SPLINED COUPLING
23
1
75/76 1
1 618 045 022 STRAP-SHAPED HANDLE
40
1
75/77 1
1 615 805 069 BEARING PEDESTAL
32
1
75/79 2
1 613 060 050 TOOTHED SHAFT
24
1
75/80 1
1 615 500 376 BEARING END PLATE
22
1
75/81 1
1 615 500 377 BEARING END PLATE
22
1
75/173 4
1 613 490 008 TORX OVAL-HEAD SCREW
10
1
75/174 2
1 613 490 009 TORX OVAL-HEAD SCREW
11
1
75/183 2
2 916 280 013 SUPPORTING DISC
10
1
75/184 2
1 613 349 021 HEXAGON NUT
12
1
84
1
1 612 025 070 CARRYING HANDLE
35
2
86
1
2 911 011 270 HEXAGON SCREW \ DIN 931-M8x130-8.8
13
2
87
1
1 611 316 024 CLAMPING BAND
28
2
88
1
1 613 349 017 STAR KNOB \ M8 \ BLACK
19
2
89
2
1 615 132 116 CLAMPING PIECE
17
2
95
1
1 614 448 038 CONNECTING CABLE
21
1
118
1
1 610 520 003 SPACER TUBE
14
1
119
2
1 610 913 020 NEEDLE-ROLLER ASSEMBLY
13
1
120
1
1 610 910 092 NEEDLE-ROLLER BEARING \ D25xD37x17
33
1
123
1
1 610 900 030 DEEP-GROOVE BALL BEARING
29
1
126
4
2 603 490 023 TORX OVAL-HEAD SCREW \ BLACK
10
1
128
1
2 916 660 021 RETAINING RING \ 47x1,75MM, DIN 472
16
1
