Ported Enclosure
Box Volume *.54 Cu Ft.
Port Frequency (Fb) 40Hz
Port Diameter 2 Inches
Port Length 7.29 Inches
* Box is given as internal air volume including port and driver displacement.
MAW8008 RECOMMENDED ENCLOSURES
Please Note: Our suggested box volumes are given as internal air requirements
Sealed Enclosure
Box Volume * 0.34 Cu Ft.
* Box is given as internal air volume including driver
Displacement.
5 Hz 5 Hz 10 10 50 50 100 100 500 500 1000 1000
00 dB dB
Frequency Frequency
66
12 12
-6 -6
-12 -12
-18 -18
-24 -24
F3 = 39 F3 = 39
7
Ported Enclosure Ported Enclosure
Sealed Enclosure Sealed Enclosure
5 Hz 5 Hz 10 10 50 50 100 100 500 500 1000 1000
00 dB dB
Frequency Frequency
66
12 12
-6 -6
-12 -12
-18 -18
-24 -24
F3 = 55 F3 = 55
MAW8008 Amplitude Response (dB/Hz) MAW8008 Amplitude Response (dB/Hz)
MAW8008 Amplitude Response (dB/Hz) MAW8008 Amplitude Response (dB/Hz)
