Register your product and get support at

HR7782

www.philips.com/welcome

Specifications are subject to change without notice

© 2012 Koninklijke Philips Electronics N.V.

All rights reserved.

HR7782_WE_UM_V3.0

EN

User manual

DE Benutzerhandbuch
FR

Mode d’emploi

NL Gebruiksaanwijzing
IT

Manuale utente

EL Εγχειρίδιο χρήσης
ES

Manual del usuario

NO

Brukerhåndbok

FI Käyttöopas
SV Användarhandbok
DA Brugervejledning
PT

Manual do utilizador

TR

Kullanım kılavuzu

3140 035 29043

1/4

English

1 Important

Read this user manual carefully before you use the appliance, and save the user manual for

future reference.

Danger

Do not immerse the motor unit in water nor rinse it under the tap.

Warning

Never use your fingers or an object to push ingredients into the feeding tube while the

appliance is running. Only use the pusher.

Before you connect the appliance to the power, make sure that the voltage indicated

on the bottom of the appliance corresponds to the local power voltage.

Never connect this appliance to a timer switch, to avoid a hazardous situation.

If the power cord, the plug, or other parts are damaged, do not use the appliance.

If the power cord is damaged, you must have it replaced by Philips, a service center

authorized by Philips, or similarly qualified persons to avoid a hazard.

This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the appliance by a

person responsible for their safety.

For their safety, do not allow children to play with the appliance.

Never let the appliance run unattended.

If food sticks to the wall of the bowl, switch off the appliance and unplug it. Then use a

spatula to remove the food from the wall.

Be careful when you handle or clean the discs, the blade units of the food processor.

The cutting edges are very sharp.

Do not touch the blades, especially when the appliance is plugged in. The blades are

very sharp.

If the blades get stuck, unplug the appliance before you remove the ingredients that

block the blades.

Caution

Never switch off the appliance by turning the bowl, or its lids. Always switch off the

appliance by turning the knob to 0.

Unplug the appliance immediately after use.

Wait until the moving parts stop running before you remove the lid of the bowl.

Do not exceed the maximum level indication on the bowl.

Thoroughly clean the parts that come into contact with food before you use the

appliance for the first time.

Before you remove or clean the kneading accessory or discs, unplug the appliance.

Never use any accessories or parts from other manufacturers or that Philips does not

specifically recommend. If you use such accessories or parts, your guarantee becomes

invalid.

This appliance is intended for household use only.

Do not exceed the quantities and processing time indicated in the user manual.

Let hot ingredients cool down (< 80ºC) before processing them.

Always let the appliance cool down to room temperature after each batch that you

process.

Certain ingredients may cause discolorations on the surface of the parts. This does not

have a negative effect on the parts. The discolorations usually disappear after some

time.

Noise level = 85 dB [A]

Electromagnetic fields (EMF)

This Philips appliance complies with all standards regarding electromagnetic fields (EMF). If

handled properly and according to the instructions in this user manual, the appliance is safe

to use based on scientific evidence available today.

Recycling

Your product is designed and manufactured with high quality materials and components,

which can be recycled and reused.

When you see the crossed-out wheel bin symbol attached to a product, it means the

product is covered by the European Directive 2002/96/EC:

Never dispose of your product with other household waste. Please inform yourself about

the local rules on the separate collection of electrical and electronic products. The correct

disposal of your old product helps prevent potentially negative consequences on the

environment and human health.

2 Introduction

Congratulations on your purchase and welcome to Philips! To fully benefit from the support

that Philips offers, register your product at www.philips.com/welcome.

For recipes to use with your food processor, go to www.philips.com/kitchen

3 Food processor

Warning

Never use your fingers or an object (for example, a spatula) to push ingredients into the feeding

tube while the appliance is running. Only use the pusher.

Chopper knife

Before you start, make sure you assemble according to Fig. 2.

You can use the chopper knife to chop, mix, blend, or puree ingredients. You can also use it to

mix and blend cake batters.

Caution

Do not use the chopper knife to chop hard ingredients, like coffee beans, turmeric, nutmeg, and ice cubes, as this

may cause the blade to get blunt.

Note

Do not let the appliance run too long when you chop (hard) cheese or chocolate. Otherwise these

ingredients become too hot, start to melt, and turn lumpy.

Precut large pieces of food into pieces of approx. 3 x 3 x 3 cm.

1

Turn the the bowl clockwise to fix it on the motor unit, and then put the tool holder

in the bowl.

»

When the bowl is fixed correctly, you hear a click.

2

Put the chopper knife on the tool holder.

3

Put the ingredients in the bowl.

4

Put the lid on the bowl, and then turn the lid clockwise to fix it.

»

When the lid is assembled correctly, you hear a click and the lid is fixed to the

bowl handle.

5

Put the pusher into the feeding tube.

6

Connect the power plug to the power supply.

7

Check the preparation time, the maximum amount and the speed setting required for

the ingredients in Table 1. Turn the knob to the desired speed setting.

8

After use, turn the knob to 0, and then unplug the appliance.

Tip

When you chop onions, turn the knob to P a few times to prevent the onions from becoming too

finely chopped.

When the food sticks to the blade or inside the bowl, you can do the following steps: 1. Switch off

the appliance, and then unplug it. 2. Remove the lid from the bowl. 3. Remove the ingredients from

the blade or from the side of the bowl with a spatula.

Serrated blade

Before you start, make sure you assemble according to Fig. 3.

Use the serrated blade to crush frozen fruit.

Note

Always put the blade unit in the bowl before you start.

It is recommended to cut the fruit into 2x2x2cm cube size before having it frozen.

For making fruit desserts, it is recommended to use speed 2 for smooth result, and speed 1 for

chunky result.

1

Turn the the bowl clockwise to fix it on the motor unit, and then put the tool holder

in the bowl.

»

When the bowl is fixed correctly, you hear a click.

2

Put the serrated ice blade on the tool holder.

3

Put the frozen fruit in the bowl.

4

Put the lid on the bowl, and then turn the lid clockwise to fix it.

»

When the lid is assembled correctly, you hear a click and the lid is fixed to the

bowl handle.

5

Put the pusher into the feeding tube.

6

Connect the power plug to the power supply.

7

Turn the knob to 1 or 2 .

8

After use, turn the speed selector to 0, and then unplug the appliance.

Kneading accessory

Before you start, make sure you assemble according to Fig. 4.

You can use the kneading tool to knead yeast dough for bread and pizzas. You need to

adjust the amount of liquid to form the dough according to the humidity and temperature

condition.

Note

Do not use the kneading tool to blend cake batters. Use the chopper knife for this job.

Always put the kneading tool in the bowl before you add the ingredients.

Tip

If using High Gluten Flour, for best results, use 60g water for every 100g of flour, and knead at speed

1 for 2 minutes (max time).

1

Turn the the bowl clockwise to fix it on the motor unit, and then put the tool holder

in the bowl.

»

When the bowl is fixed correctly, you hear a click.

2

Put the kneading tool on the tool holder.

3

Put the ingredients in the bowl.

4

Put the lid on the bowl, and then turn the lid clockwise to fix it.

»

When the lid is assembled correctly, you hear a click and the lid is fixed to the

bowl handle.

5

Put the pusher into the feeding tube.

6

Connect the power plug to the power supply.

7

Turn the knob to the 1 position.

8

Check the preparation time, the maximum amount and the speed setting required for

the ingredients in Table 1.

9

After use, turn the knob to 0, and then unplug the appliance.

Balloon beater

Before you start, make sure you assemble according to Fig. 5:

1

Put the tool holder in the bowl.

2

Put the balloon beater on the tool holder in the bowl.

3

Put the ingredients in the bowl.

4

Put the lid on the bowl. Turn the lid clockwise to fix it. Put the pusher in the feeding

tube.

5

Select speed 1.

6

After use, turn the speed selector to 0, and then unplug the appliance.

Citrus press

Before you start, make sure you assemble according to Fig. 6.

You can use the citrus press to squeeze citrus fruits.

1

Turn the the bowl clockwise to fix it on the motor unit, and then put the tool holder

in the bowl.

»

When the bowl is fixed correctly, you can hear a click .

2

Put the sieve for citrus press on the tool holder in the bowl. Make sure that the

projection on the sieve is locked in the slot of the bowl handle.

»

When the sieve is fixed correctly, you can hear a click .

3

Put the cone on the sieve.

4

Connect the power plug to the power supply.

5

Check the maximum amount required for the ingredients in Table 1. Turn the knob to

speed 1.

»

The cone starts rotating.

6

Press the citrus fruit onto the cone.

7

Stop pressing from time to time to remove the pulp from the sieve. When you finish

pressing or when you want to remove the pulp, turn the knob to 0 and remove the

bowl from the appliance with the sieve and cone on it.

Slicing discs and shredding discs

Before you start, make sure you pick your desired disc and assemble according to Fig. 7:

Adjustable slicing disc to adjust different thickness

Reversible shredding disc (bigger or small size)

Caution

Be careful when you handle the disc. It has a very sharp cutting edge.

Never use the disc to process hard ingredients, like ice cubes.

Do not exert too much pressure on the pusher when you press ingredients into the feed tube.

4 Cleaning

Warning

Before you clean the appliance, unplug it.

Caution

Make sure that the cutting edges of the blades and discs do not come into contact with hard objects.

This may cause the blade to get blunt.

The cutting edges are sharp. Be careful when you clean the blade unit of the food processor and the

discs.

1

Clean the motor unit with a moist cloth.

2

Clean the other parts in hot water (< 60ºC) with some washing-up liquid or in a

dishwasher.

Quick cleaning

You can follow the following steps to clean the food processor bowl and blender jar easier.

Note

Make sure that the blade is assembled in the bowl if you clean the food processor bowl.

1

Pour lukewarm water (not more than 0.5 liters) and a few drops of washing-up liquid

into the food processor bowl.

2

Place the lid on the food processor bowl, and then turn it clockwise to fix it.

3

Turn the knob to P. Let the appliance run for 30 seconds or until the food processor

bowl is clean.

4

After use, turn the knob to 0, and then unplug the appliance.

5

Detach the food processor bowl and rinse it with clean water.

5 Storage

1

Push the power cord into the integrated cord storage (Fig. 10).

2

Store the product in a dry place.

3

Put the discs, kneading tool and shaft, and other small accessories in the food processor

bowl (Fig. 11).

6 Guarantee and service

If you have a problem, need service, or need information, see www.philips.com/support or

contact the Philips Consumer Care Center in your country. The phone number is in the

worldwide guarantee leaflet. If there is no Consumer Care Center in your country, go to

your local Philips dealer.

1

2 min

1 kg

1

20 sec

500 g

1

30 sec

1 kg

1

30 sec

200 g

1

30 sec

3 pcs

1

30 sec

1 kg

1

(MAX)

(MAX)

(MAX)

(MAX)

5 x 1 sec

750 g

P

5 x 1 sec 1 kg

P/2

30 sec

100 g

P

60 sec

1 kg

2

45 sec

500 g

2

30 sec

400 g

2

750 ml

8 pcs

1

1

30 sec

1 kg

1

30 sec

1 kg

1

2 min

1 kg

600 ml

1

60-180 sec

60-300 sec

P

0

1

2

30 sec

750 g

1

30 sec

3 pcs

1

30 sec

3 pcs

1

750 g

1-2

60-180 sec

-4

o

C

10

11

12

0

1

P

2

9

6

5

2

3

4

-4

o

C

8

7

This manual is related to the following products:
