Overview
5
Specifications
Part No.: F1DD102L, F1DD104L
Power: 9V, 1A DC adapter with center
pin-positive polarity
PCs Supported: 2 (F1DD102L), 4 (F1DD104L)
Console Keyboard: USB
Console Mouse: USB
Monitor Supported: DVI-D
Max Resolution: 1920x1200
Audio Input/Output: 3.5mm jack
Microphone Input/Output: 3.5mm jack
DVI Port:
DVI-D
LED Indicators: 4 (F1DD102L), 8 (F1DD104L)
Enclosure: High-impact plastic
Dimensions: F1DD102L
12.5 (L) x 5.5 (W) x 5.5 (D) in.
(317.5 x 139.7 x 139.7mm)
F1DD104L
12.5 (L) x 5.5 (W) x 5.5 (D) in.
(317.5 x 139.7 x 139.7mm)
Weight: F1DD102L
1.48 lbs. (0.67kg)
F1DD104L
1.50 lbs. (0.68kg)
Operating Temp: 32° to 104° F (0° to 40° C)
Storage Temp: -4° to 140° F (-20° to 60° C)
Humidity: 0-80% RH, non-condensing
Warranty: 3 years
Note: Specifications are subject to change without notice.
