BOXLIGHT SP-5t - Manual (Page 5)

5
TABLE OF CONTENTS
FEATURES AND DESIGN 6
BEFORE OPERATION 14
COMPUTER MODE 22
VIDEO MODE 29
SETTING 32
APPENDIX 34
PREPARATION 7
NAME OF EACH PART OF THE PROJECTOR 7
SETTING-UP THE PROJECTOR 8
CONNECTING THE AC POWER CORD 8
POSITIONING THE PROJECTOR 9
ADJUSTABLE FEET 9
MOVING THE PROJECTOR 10
CONNECTING THE PROJECTOR 11
TERMINALS OF THE PROJECTOR 11
CONNECTING TO THE VIDEO EQUIPMENT 12
CONNECTING TO THE COMPUTER 13
OPERATION OF THE REMOTE CONTROL 14
OPERATING RANGE 14
REMOTE CONTROL BATTERIES INSTALLATION 15
TOP CONTROLS AND INDICATORS 16
OPERATING ON-SCREEN MENU 17
HOW TO OPERATE THE ON-SCREEN MENU 17
FLOW OF ON-SCREEN MENU 17
MENU BAR 18
SELECTING COMPUTER MODE 22
SELECTING COMPUTER SYSTEM 22
COMPATIBLE COMPUTER SPECIFICATIONS 23
PC ADJUSTMENT 24
PICTURE IMAGE ADJUSTMENT 26
ADJUST PICTURE IMAGE MANUALLY 26
NORMAL FUNCTION 26
AUTO IMAGE FUNCTION 27
PICTURE POSITION ADJUSTMENT 27
PICTURE SCREEN ADJUSTMENT 28
SELECTING VIDEO MODE 29
SELECTING VIDEO SOURCE 29
SELECTING COLOR SYSTEM 30
PICTURE SCREEN ADJUSTMENT 30
PICTURE IMAGE ADJUSTMENT 31
ADJUSTING THE PICTURE IMAGE MANUALLY 31
NORMAL FUNCTION 31
SETTING MENU 32
SETTING LANGUAGE 33
OPERATING WIRELESS MOUSE 34
MAINTENANCE 35
TEMPERATURE WARNING INDICATOR 35
AIR FILTER CARE AND CLEANING 35
CLEANING THE PROJECTION LENS 35
LAMP REPLACEMENT 36
LAMP REPLACEMENT MONITOR TIMER 36
TROUBLESHOOTING 37
TECHNICAL SPECIFICATIONS 39
BASIC OPERATION 19
TURNING ON / OFF THE PROJECTOR 19
ADJUSTING THE IMAGE 20
ZOOM ADJUSTMENT 20
FOCUS ADJUSTMENT 20
KEY STONE ADJUSTMENT 20
NO SHOW FUNCTION 21
PICTURE FREEZE FUNCTION 21
P-TIMER FUNCTION 21
SOUND ADJUSTMENT 21
SOUND VOLUME ADJUSTMENT 21
SOUND MUTE ADJUSTMENT 21
