INSTALLATION
CONNECTING TO AV EQUIPMENTS
-10-
It can be connected to the following appliances: VCR, multi disc player, DVD, camcorder,
video game or stereo system
as well as a number of other electronic items.
YPbPr can support these video fomats:480i,576i,480p,576p,720p,1080i,1080p.
This TV provides one group of AV, one S-Video,one group of YPbPr for convenient
connection to VCR, DVD or other video equipment. Please refer to the owner s manual
of the equipment to be connected as well.
You can use the input terminals on TV set rear as follows.
To audio
outputs
with
terminal
VIDEO EQUIPMENT
To audio outputs
with S-video
term inal
VIDEO EQUIPMENT
To S-VIDEO
output
Yellow (video)
White(audio L)
Red(audio R or Pr)
Y
W
R
R
W
Y
W R
output
To video
Blue(Pb)
Green(Y)
B
G
VIDEO EQUIPMENT with YPbPr
Y W R
W R
G B R
G B R
Y
From Coaxial SPDIF
output
VIDEO RECORDER
Y
with SPDIF Input
term inal
100-240V~ 50/60Hz
AC-INPUT
AUDIO
VGA INPUT VGA INPUT
L
R
AV
S-VIDEO
HDMI ANT
AUDIO
INPUT
Pr Y
Pb SPDIF OUTPUT
YPbP
r
INPUT
