Exploded Views and Parts Lists
PARTS LIST - MAIN UNIT
Item
Part #
Description
1
187757GS
BOLT, CVR, MFFLR
2
197871GS
DECAL, ON-OFF
3
187450GS
SWITCH, ENG, ON/OFF
4
187766GS
DECAL, CHOKE
5
197843GS
SPPRT, RECOIL
6
187761GS
NUT, M4, FLNG
7
187760GS
SCREW, M4X12
8
191545GS
DECAL, FUEL SHUTOFF, 4-L, CCW
9
197829GS
PNL, END, RECOIL
10
197882GS
FILLER, FOAM
11
197831GS
PNL, SIDE, MFFLR
12
197860GS
BOLT, M6X16
13
197872GS
DECAL, SPECS
14
191436GS
DECAL, CAUTION, HOT MFFLR, 4
LANG
15
197828GS
PNL, END, CNTRL
16
197881GS
U-PACKING
17
187763GS
DECAL, CAUTION, OIL
18
197870GS
DECAL, UNIT
19
197830GS
PNL, SIDE, OIL
20
187876GS
CABLE, BTTRY CHARGE, ACC
PLUG
21
187460GS
BRKR, CRCT, 10A, 125V
22
197873GS
DECAL, DC OUT
23
197875GS
CNNCTR
24
197876GS
CNNCTR
25
187873GS
OUTLET, 12V DC, ACCSSRY
26
187415GS
PHMS, M5-0.8 X 20
27
197874GS
WSHR, LCK, INTRNL
28
187423GS
NUT, M5 X 0.8
29
187424GS
NUT,WING, M5 X 0.8
30
197863GS
SCREW, M4X12, SLFTAP
31
197854GS
PNL, CNTRL
32
197855GS
BRKR, CRCT, 15A, 125V
33
187456GS
RCPTCL, 15 A, 125 V
34
187436GS
CAP, FUEL
35
197883GS
PACKING,TANK
36
187438GS
STRAINER, FUEL
37
197864GS
BOLT, M6X20, FLNG
38
197866GS
WSHR, FLAT
39
197865GS
SLEEVE
Item
Part #
Description
40
197832GS
TANK, FUEL
41
187440GS
FLTR, FUEL
42
187443GS
VLV, FUEL
43
187579GS
CLIP, HOSE
44
197845GS
CLIP, NYLN
45
197844GS
HOSE, FUEL
46
197834GS
HNDL
47
197835GS
HNDL,TUBE
48
197867GS
GRIP, HNDL
49
197862GS
SCREW
50
197838GS
MNT,VBRTN,TANK
51
197861GS
NUT, M6, FLNG
52
200231GS
ASSY, HTSHLD,TANK
53
187401GS
NUT, M8, FLNG
54
197848GS
BRCKT, PNL
55
197846GS
BASE, ENG
56
197851GS
MNT,VBRTN
57
197857GS
BOLT, M8X35, FLNG
58
197858GS
BOLT, M8X16, FLNG
59
200230GS
ASSY, BASE, ALT
60
197852GS
AXLE
61
197869GS
PIN
62
197868GS
WSHR, FLAT
63
197853GS
WHL
64
197839GS
HTSHLD, MFFLR
65
197859GS
BOLT, M5X12, FLNG
66
197880GS
SCREW, M3-8, SLFTAP
67
197878GS
PIPE,TAIL
68
197879GS
SCREW, M4X16
69
197877GS
ARRSTR, SPARK
70
197842GS
MFFLR
71
197856GS
CONDENSOR, 350V
72
197841GS
HTSHLD, ALT
73
197840GS
BRCKT, HTSHLD
899
ALTERNATOR (See page 5)
900
ENGINE (See pages 6-8)
Parts Not Illustrated
197561GS
MANUAL, Owners
BB3061BGS
BOTTLE, Oil
