All power ratings conform to CEA-2006 standards.
PARAMETER/FEATURE PCA460
Channels 4/3/2
Size ( W x H x D) 10x1.9x12 inches (254x49x305mm)
Weight 6.0 lbs (2.7 kg)
Spade screw speaker terminals? YES
Maximum terminal wire size 14 ga.
Subsonic filter YES (10 Hz)
Separate front/rear or left/right gains? F/R-YES L/R-NO
Fuse Type ATC spade -Two 30A
Speaker short, short to +12V, and short to ground protection? YES
High, low, and reverse voltage protection? YES
Power output transistors BTL
Power supply transistors MOSFET
Minimum speaker impedance (non-bridged) 2 ohms
(bridged) 4 ohms
PERFORMANCE DATA
Rated power output @ 0.1% THD, 14.4V (CEA-2006)
4 channels into 4 ohms / 2 ohms (watts rms) 4 x 60 W / 4 x 80 W
2 channels into 4 ohms (watts rms) 2 x 120 W
Max Dynamic Power (watts rms) 300W
Total Harmonic Distortion @ full power 0.1% THD
Signal/Noise ratio (gain controls in center)
Measured @ 1 watt / 1 kHz dBA >80
Measured @ full rated power (0.1% THD) dBA >97
Damping factor >100
Frequency response (full-range mode) 20 - 30,000 Hz
High-pass crossover frequency limits 50 H z - 250 Hz (variable), 12dB/oct
Low-pass crossover frequency limits 50 H z - 250 Hz (variable), 12dB/oct
Bass Boost Variable (0-12dB)
Input impedance 10 kohms
Input signal voltage control range 0.3 - 6.0 vrms
Current Draw @ 13.8 VDC (typical values @ X watts / Efficiency %)
@ full rated power, unbridged (@ 4 ohms) 34 A (50%)
@ 33% rated power, unbridged (@ 4 ohms) 17 A (35%)
@ idle (@ 4 ohms) 2.5 A
Minimum battery voltage to maintain rated power 13.8 VDC
Usable battery voltage 10 - 16 VDC
Trigger line voltage range 10 - 16 VDC
Trigger line current draw < 10 mA
Turn on delay time @ 2.0 seconds
Thermal shutoff temperature (average heat-sink temp) @ 85˚ C (185˚ F)
NOTE: DUE TO ONGOING PRODUCT IMPROVEMENTS, DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE
WITHOUT ADVANCED NOTICE TO THE CONSUMER OR RETAILER.
B LAUPUNKT S PECIFICATIONS -
PCA460, 4/3/2 C HANNEL A MPLIFIER
