Specifications
20PFL3403/10
LCD TV with Crystal Clear III
51 cm (20")
Highlights
Crystal Clear III
Crystal Clear III combines a whole range of
enhancements to provide a better picture. They
include a 2D Comb filter, Dynamic contrast, Blue
stretch and Green enhancement so that you always
get the most natural looking colors.
LCD display, 640 x 480p
LCD display, 640 x 480p
Incredible Surround
Incredible Surround is an audio technology from
Philips that dramatically magnifies the sound field to
immerse you in the audio. Using state-of-the-art
electronic phase shifting, Incredible Surround mixes
sounds from left and right in such a way that it
expands the virtual distance between the two
speakers. This wider spread greatly enhances the
stereo effect and creates a more natural sound
dimension. Incredible Surround allows you to
experience total surround with greater depth and
width of sound, without the use of additional
speakers.
HDMI input
HDMI makes an uncompressed digital RGB
connection from the source to the screen. By
eliminating conversion to an analog signal, it delivers
an unblemished image. The non-degraded signal
reduces flicker and leads to a clearer picture. HDMI
intelligently communicates the highest output
resolution with the source device. The HDMI input
is fully backward compatible with DVI sources but
includes digital audio. HDMI uses HDCP copy
protection.
PC input (VGA)
With PC input you can connect your TV to a
computer by a VGA cable and use the TV as a PC
monitor.
Smart Picture and Smart Sound
Philips preset modes for Smart Picture and Smart
Sound provide you with direct access via a single key
on the remote control. You can select optimized
picture and sound settings for the various picture
and sound modes.
TV (75 Ω)
EXT 2 EXT 3 EXT 1
AUDIO
VGA
Y Pr
R
VIDEO
L
Pb
VGA PC HDMI
Picture/Display
• Aspect ratio: 4:3
• Brightness: 300 cd/m²
• Contrast ratio (typical): 800:1
• Response time (typical): 12 ms
• Viewing angle: 178º (H) / 178º (V)
• Diagonal screen size: 20 inch / 51 cm
• Display screen type: LCD VGA Active Matrix TFT
• Panel resolution: 640 x 480p
• Picture enhancement: Crystal Clear III, 2D
Combfilter, 3/2 - 2/2 motion pull down, White
stretch, Progressive scan, Smart Picture
• Screen enhancement: Anti-Reflection coated
screen
Supported Display Resolution
• Computer formats
Resolution Refresh rate
640 x 480 60Hz
• Video formats
Resolution Refresh rate
480i 60Hz
480p 60Hz
576i 50Hz
576p 50Hz
Sound
• Output power (RMS): 2 x 3W
• Sound Enhancement: Auto Volume Leveller,
Incredible Surround, Smart Sound
• Sound System: Mono, Stereo
Convenience
• Clock: Sleep Timer, Start timer, Stop timer
• Ease of Installation: Auto Program Naming,
Automatic Channel Install(ACI), Automatic Tuning
System (ATS), Autostore, Fine Tuning, Plug & Play
• Ease of Use: Auto Volume Leveller (AVL), On
Screen Display, Program List, Side Control, Smart
Picture, Smart Sound
• Picture in Picture: Text dual screen
• Remote Control: TV
• Remote control type: RC5
• Screen Format Adjustments: 4:3
• Teletext: 100 page Smart Text
Tuner/Reception/Transmission
• Aerial Input: 75 ohm coaxial (IEC75)
• TV system: PAL I, PAL B/G, PAL D/K, SECAM B/G,
SECAM D/K, SECAM L/L'
• Video Playback: NTSC, SECAM, PAL
• Tuner bands: Hyperband, S-Channel, UHF, VHF
Connectivity
• Ext 1 Scart: Audio L/R, CVBS in/out, RGB
• Ext 2: YPbPr in, CVBS in, Audio L/R in
• Ext 3: S-video in
• Ext 4: HDMI
• Other connections: Headphone out, PC Audio in,
PC-In VGA
Power
• Ambient temperature: 5 °C to 35 °C
• Mains power: 100-240V,50/60Hz
• Power consumption: 45 W
• Standby power consumption: <0.3 W
Dimensions
• Set dimensions (W x H x D): 470 x 406 x 71 mm
• Set dimensions with stand (W x H x D):
470 x 448 x 205 mm
• Weight incl. Packaging: 9.7 kg
• Product weight: 5.8 kg
• Product weight (+stand): 6.7 kg
• Box dimensions (W x H x D):
572 x 500 x 225 mm
• VESA wall mount compatible: 100 x 100 mm
Accessories
• Included accessories: Table top stand, Power cord,
Quick start guide, User Manual, Warranty
certificate, Remote Control, Batteries for remote
control
•
