14
SPECIFICATIONS
Specifications
Video input:
Composite Video, 1.0 Vpp, 75 ohms
Audio input:
0 - 1.0 Vrms, 20 Hz - 20 kHz (Booster
off)
0 - 0.3 Vrms, 20 Hz - 20 kHz (Booster
on)
Video output:
Composite Video, 1.0 Vp-p, 75 ohms
Audio output:
0 - 1.0 Vrms, 20 Hz - 20 kHz
Power supply:
DC 12V, +/- 10%, max. 4A
Operating temperature:
-20
°
to + 70
°
Celsius
Dimensions:
205 x 45 x 146 mm (W x H x D)
Features
3 Audio inputs:
Cinch jacks
3 Video inputs:
Cinch jacks
3 monitor outputs:
CCVS, 13-pin jack, with power, earth,
switching positive and control
1 Audio output:
Cinch jacks
10dB booster on/off
IR remote control
IR receiver
Power input:
4-pin plug-type connector
Metal housing
