Philips Plancha multiestilo User Manual
Salon

Register your product and get support at
www.philips.com/welcome
HP8698
PT Manual do utilizador
PT-BR Manual do Usuário
EN User manual
ES
Manual pengguna
5
24
3
7~10
sec.
6
7
4
7~10
sec.
a
d
e
c
b
f
g
h
i
j
k
l
m
o
p
q
r
s
t
u
n
Salon
v
English
Congratulations on your purchase, and welcome to Philips! To fully
EHQHÀWIURPWKHVXSSRUWWKDW3KLOLSVRIIHUVUHJLVWHU\RXUSURGXFWDW
www.philips.com/welcome.
1 Important
Read this user manual carefully before you use the appliance and keep it
for future reference.
WARNING: Do not use this appliance
near water.
When the appliance is used in a
bathroom, unplug it after use since
the proximity of water presents a risk,
even when the appliance is switched
off.
WARNING: Do not use this appliance
near bathtubs, showers, basins
or other vessels containing
water.
Always unplug the appliance
after use.
If the mains cord is damaged, you
must have it replaced by Philips, a
service centre authorised by Philips or
VLPLODUO\TXDOLÀHGSHUVRQVLQRUGHUWR
avoid a hazard.
This appliance can be used by
children aged from 8 years and above
and persons with reduced physical,
sensory or mental capabilities or
lack of experience and knowledge
if they have been given supervision
or instruction concerning use of
the appliance in a safe way and
understand the hazards involved.
Children shall not play with the
appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
Before you connect the appliance,
ensure that the voltage indicated on
the appliance corresponds to the local
power voltage.
Do not use the appliance for any
other purpose than described in this
manual.
When the appliance is connected to
the power, never leave it unattended.
Never use any accessories or
parts from other manufacturers
RUWKDW3KLOLSVGRHVQRWVSHFLÀFDOO\
recommend. If you use such
accessories or parts, your guarantee
becomes invalid.
Do not wind the mains cord round
the appliance.
Wait until the appliance has cooled
down before you store it.
Pay full attention when using the
appliance since it could be extremely
hot. Only hold the handle as other
parts are hot and avoid contact with
the skin.
Always place the appliance with the
VWDQGRQDKHDWUHVLVWDQWVWDEOHÁDW
surface. The hot heating plates/barrel
should never touch the surface or
RWKHUÁDPPDEOHPDWHULDO
Avoid the mains cord from coming
into contact with the hot parts of the
appliance.
Keep the appliance away from
ÁDPPDEOHREMHFWVDQGPDWHULDOZKHQ
it is switched on.
Never cover the appliance with
anything (e.g. a towel or clothing)
when it is hot.
Only use the appliance on dry hair. Do
not operate the appliance with wet
hands.
Keep the heating plates/barrel clean
and free of dust and styling products
such as mousse, spray and gel.
The heating plates/barrel has coating.
This coating might slowly wear
away over time. However, this does
not affect the performance of the
appliance.
If the appliance is used on color-
treated hair, the heating plates/barrel
may be stained. Before using it on
DUWLÀFLDOKDLUDOZD\VFRQVXOWWKHLU
distributor.
Always return the appliance to a
service centre authorized by Philips
for examination or repair. Repair by
XQTXDOLÀHGSHRSOHFRXOGUHVXOWLQDQ
extremely hazardous situation for the
user.
'RQRWLQVHUWPHWDOREMHFWVLQWR
openings to avoid electric shock.
(OHFWURPDJQHWLFÀHOGV(0)
This Philips appliance complies with all applicable standards and
UHJXODWLRQVUHJDUGLQJH[SRVXUHWRHOHFWURPDJQHWLFÀHOGV
Environment
Do not throw away the appliance with the normal household
ZDVWHDWWKHHQGRILWVOLIHEXWKDQGLWLQDWDQRIÀFLDOFROOHFWLRQ
point for recycling. By doing this, you help to preserve the
environment.
2
Style your hair
Note: Do not change the attachments or styler when the appliance is
heating up or when it is hot. Let the appliance heat up for 3-5 minutes
for perfect styling results. When unwinding the section of the hair
after curling, do not pull at the hair as it would straighten the curl.
Select a suitable attachment and styler for the hairstyle you want.
Hairstyle
Attachment
Tight curls
Small curling attachment ( )
Waves
Small curling attachment ( ) and Slide-on
brush ( )
Crimps
Crimping/straightening attachment ( ) with
curved surfaces ( ) facing towards each
other
Straight sleek style
DQGÁLFNV
Crimping/straightening attachment ( ) with
ÁDWVXUIDFHV ) facing towards each other
Before you style your hair:
1 Ensure arrow on the ring is pointing at unlock icon on the handle
( ).
2 Slide a suitable attachment onto the metal tube ( ) of the handle
( ) and turn the ring to the right/anti-clockwise to lock it ( ).
To remove the attachment, turn the ring to the left/clockwise to
unlock ( ) and pull it off.
3 Connect the plug to a power supply socket.
4 Slide the on/off switch ( ) to I to switch on the appliance.
»
The power-on indicator ( ) lights up and starts blinking.
»
When the appliance is ready for use, the indicator stops blinking.
5 Place the appliance with the support ( ) on a heat-resistant
surface.
6 Comb your hair and divide your hair into small sections that are not
wider than 2-4cm.
&UHDWHFXUOVRUULQJOHWV)LJ
1 Select small curling attachment ( ) for styling tight curls and
ringlets.
2 Press the lever ( ) to open the clip ( ) and place a section of
hair between the clip and barrel ( ).
3 Release the lever and slide the barrel to the hair tip.
4 Hold the end of the cool tip ( ) and the handle ( ). Then wind
the section of hair round the barrel from end to root.
5 Hold the barrel in the position for max. 10 seconds. Then unwind the
section of hair until you can open the clip again with the lever.
6 To style the rest of your hair, repeat steps 2 to 5.
&UHDWHZDYHV)LJ
1 Select the small curling attachment ( ). Then slide the Slide-on
brush ( ) onto barrel.
2 Wind a section of hair round the brush.
3 Hold the barrel in the position for max.10 seconds. Then unwind the
section of hair to remove the Slide-on brush ( ) from your hair.
4 To style the rest of your hair, repeat steps 2-3.
&UHDWHFULPSV)LJ
1 Select crimping/straightening attachment ( ).Make sure that the
curved surfaces ( ) are facing each other.
To remove the the crimping/straightening plates, grab each
protruded side of the plate ( ) and pull it off.
2 Press the lever ( ) to open the attachment and place a section of
hair between the crimping plates.
3 Release the lever and keep the plates together for 5 to 10 seconds.
4 Press the lever to open the plates and place the next section of hair
between the plates. Make sure there is an overlap.
5 Repeat this process until you have reached the hair tip.
6 To style the rest of your hair, repeat steps 2 to 5.
&UHDWHVWUDLJKWVOHHNVW\OHDQGÁLFNV)LJ
1 0DNHVXUHWKDWWKHÁDWVXUIDFHV ) are facing each other. Press
the lever ( ) to open the attachment and place a section of hair
between the straightening plates.
2 Slide down slowly the length of the hair in a single motion from root
to end, without stopping to prevent overheating.
7RFUHDWH\RXUGHVLUHGW\SHRIÁLFNWXUQWKHVW\OHUKDOIFLUFOH
inwards (or outwards) when it reaches the last 3-5 cm of the hair
tip. Hold in that position for 2 to 3 seconds, and then release it.
3 To style the rest of your hair, repeat steps 1 to 2.
Note: The appliance is equipped with an auto-shut off function. After
60 minutes, the appliance switches off automatically. You can re-start
the appliance by sliding the ON/OFF switch to | to power on the styler
again.
After use:
1 Switch off the appliance and unplug it.
2 Place it on a heat-resistant surface until it cools down.
3 Remove hairs and dust from the appliance and attachments.
4 Clean the appliance and attachments by damp cloth.
5 Keep the appliance in a safe and dry place, free of dust. You can also
hang it with the hanging loop ( ) or store it in the supplied heat
resistant pouch ( ).
3
Guarantee and service
If you need information e.g. about replacement of an attachment or if
you have a problem, please visit the Philips website at www.philips.com
RUFRQWDFWWKH3KLOLSV&XVWRPHU&DUH&HQWUHLQ\RXUFRXQWU\\RXÀQG
LWVSKRQHQXPEHULQWKHZRUOGZLGHJXDUDQWHHOHDÁHW,IWKHUHLVQR
Consumer Care Centre in your country, go to your local Philips dealer.
Español
Le felicitamos por su compra y le damos la bienvenida a Philips. Para
EHQHÀFLDUVHWRWDOPHQWHGHODDVLVWHQFLDTXHRIUHFH3KLOLSVUHJLVWUHVX
producto en www.philips.com/welcome.
1 Importante
Antes de usar el aparato, lea atentamente este manual de usuario y
consérvelo por si necesitara consultarlo en el futuro.
ADVERTENCIA: No utilice este
aparato cerca del agua.
Si utiliza el aparato en el cuarto de
baño, desenchúfelo después de usarlo.
La proximidad de agua representa
un riesgo, aunque el aparato esté
apagado.
ADVERTENCIA: No utilice este
aparato cerca del agua ni cerca de
bañeras, duchas, cubetas
u otros recipientes que
contengan agua.
Desenchufe siempre el
aparato después de usarlo.
Si el cable de alimentación está
dañado, deberá ser sustituido por
Philips, por un centro de servicio
autorizado por Philips o por personal
FXDOLÀFDGRFRQHOÀQGHHYLWDU
situaciones de peligro.
Este aparato puede ser usado por
niños a partir de 8 años y por
personas con su capacidad física,
psíquica o sensorial reducida y por
quienes no tengan los conocimientos
y la experiencia necesarios, si han
sido supervisados o instruidos acerca
del uso del aparato de forma segura
y siempre que sepan los riesgos que
conlleva su uso. No permita que
ORVQLxRVMXHJXHQFRQHODSDUDWR
Los niños no deben llevar a cabo
la limpieza ni el mantenimiento sin
supervisión.
Antes de enchufar el aparato,
FRPSUXHEHTXHHOYROWDMHLQGLFDGR
en el mismo se corresponde con el
YROWDMHGHODUHGHOpFWULFDORFDO
No utilice este aparato para otros
ÀQHVGLVWLQWRVDORVGHVFULWRVHQHVWH
manual.
1XQFDGHMHHODSDUDWRVLQYLJLODQFLD
cuando esté enchufado a la red
eléctrica.
No utilice nunca accesorios ni piezas
de otros fabricantes o que Philips no
UHFRPLHQGHHVSHFtÀFDPHQWH6LOR
hace, quedará anulada su garantía.
No enrolle el cable de alimentación
alrededor del aparato.
Espere a que se enfríe el aparato
antes de guardarlo.
Preste total atención cuando utilice
el aparato, ya que puede estar muy
caliente. Agarre solo el mango, ya que
el resto de piezas están calientes, y
evite el contacto con al piel.
Coloque siempre el aparato con el
VRSRUWHVREUHXQDVXSHUÀFLHSODQD
estable y resistente al calor. Las placas
de calentamiento o el cilindro caliente
QXQFDGHEHQWRFDUVXSHUÀFLHVQLRWURV
PDWHULDOHVLQÁDPDEOHV
Evite que el cable de alimentación
entre en contacto con las piezas
calientes del aparato.
0DQWHQJDHODSDUDWROHMRVGHREMHWRV
\PDWHULDOHVLQÁDPDEOHVPLHQWUDVHVWp
encendido.
Specifications are subject to change without notice
© 2014 Koninklijke Philips N.V.
All rights reserved.
3140 035 38272
