Briggs & Stratton 124L00 - Manual (Page 9)

124L00
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
3976−9 Assemblies include all parts shown in frames. 05/20/2008
9
305 691108 Screw
(Blower Housing)
306 690450 Shield−Cylinder
307 690345 Screw
(Cylinder Shield)
309A 795092 Motor−Starter
332 690662 Nut
(Flywheel)
333 802574 Armature−Magneto
334 691061 Screw
(Magneto Armature)
337 802592S Plug−Spark
(Resistor)
339 794797 Tube/Connector
Assemble
346 690661 Screw
(Spark Arrestor)
347 691396 Switch−Rocker
356 692390 Wire−Stop
356B 693010 Wire−Stop
358 497316 Gasket Set−Engine
363 19069 Flywheel Puller
365 691688 Screw
(Carburetor)
383 89838S Wrench−Spark Plug
404 690272 Washer
(Governor Crank)
425A 690670 Screw
(Air Cleaner Cover)
443A 692523 Screw
(Air Cleaner Primer
Base)
445A 491588S Filter−Air Cleaner
Cartridge
455 791960 Cup−Flywheel
456 692299 Plate−Pawl Friction
459 281505S Plate−Ratchet
474 691991 Alternator
497 690664 Screw
(Stop Switch Bracket)
505 691251 Nut
(Governor Control
Lever)
510 795093 Drive−Starter
513 692358 Drive−Clutch
523 499621 Dipstick
524 K692296 Seal−Dipstick Tube
525 495265 Tube−Dipstick
529 691923 Grommet
562 92613 Bolt
(Governor Control
Lever)
563 691138 Screw
(Debris Guard Screen)
564C 690351 Screw
(Control Cover)
584 697734 Cover−Breather
Passage
585 K691879 Gasket−Breather
Passage
592 690800 Nut
(Rewind Starter)
597 691696 Screw
(Pawl Friction Plate)
601 791850 Clamp−Hose
604E 794794 Cover−Control
608 497680 Starter−Rewind
613 691340 Screw
(Muffler)
−−−−−−− Note −−−−−
790833 Screw
(Muffler)
Used on Type No(s).
0650.
615 690340 Retainer−Governor
Shaft
616 698801 Crank−Governor
617KDz270344 Seal−O Ring
(Intake Manifold)
621 692310 Switch−Stop
627 792565 Bracket−Stop Switch
633 D
z
691321 Seal−Choke/Throttle
Shaft
633A D
z
693867 Seal−Choke/Throttle
Shaft
635 66538S Boot−Spark Plug
651 691660 Screw
(Starter Gear Cover)
668 K493823 Spacer
670 692294 Spacer−Fuel Tank
676 396548 Deflector−Muffler
676C 493871 Deflector−Muffler
677 690661 Screw
(Muffler Deflector)
684 690345 Screw
(Breather Passage
Cover)
689 691855 Spring−Detent
692 690572 Spring−Friction
697 691127 Screw
(Drive Cap)
718 690959 Pin−Locating
741 795755 Gear−Timing
703 696309 Clip
741 795755 Gear−Timing
(Plastic)
−−−−−−− Note −−−−−
794388 Gear−Timing
(Use Without Woodruff
Key)
(Used After Code Date
07093000).
790345 Gear−Timing
(Use Without Woodruff
Key)
(Used Before Code
Date 07100100).
691830 Gear−Timing
(Uses Woodruff Key)
742 93941 Retainer−E Ring
745 691648 Screw
(Brake)
783 691918 Gear−Pinion
(Starter Drive)
783A 691269 Gear−Pinion
784 795095 Cover −Starter Gear
785 692352 Gasket−Starter Cover
789B 696547 Harness−Wiring
832 499034 Guard−Muffler
836 690664 Screw
(Muffler Guard)
842 K691031 Seal−O Ring
(Dipstick Tube)
843 691884 Sleeve−Lever
843A 691895 Sleeve−Lever
847 692047 Dipstick/Tube
Assembly
851 493880S Terminal−Spark Plug
853 695268 Adapter−Wire
868 697338 Seal−Valve
K Included in Engine Gasket Set−Ref. No.358.
D Included in Carburetor Overhaul Kit−Ref. No. 121.
z
Included in Carburetor Gasket Set−Ref. No. 977.
∅ Included in Valve Gasket Set−Ref. No 1095.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
