SPECIFICATIONS
12
NOTES
SPECIFICATIONS
Generator
Rated Maximum Power (LP*) . . . 20.0 kW
Rated Maximum Load Current:
at 240 Volts . . . . . . . . . . . . . . . 83.3 Amps
at 120 Volts . . . . . . . . . . . . . . . 166.6 Amps
Rated AC Voltage . . . . . . . . . . . . . 120/240 Volts
Rated Frequency . . . . . . . . . . . . . 60 Hz at 3600 rpm
Phase . . . . . . . . . . . . . . . . . . . . . . Single Phase
Power Factor . . . . . . . . . . . . . . . . 1.0
Normal Operating Range. . . . . . -20°F (-28.8°C) to 104°F (40°C)
Output Sound Level. . . . . . . . . . 68 dB(A) at 23 ft. (7 m) at normal load
Shipping Weight . . . . . . . . . . . . 613 lbs.
* Natural gas rating will depend on specific fuel but typical derates are
between 10 to 20% off the LP gas rating.
