10 EURORACK PRO RX1602 User Manual
6. Specifications
Audio Inputs
Input L/R
Type 1/4" TRS connector,
electronically balanced
Impedance approx. 20 kΩ balanced,
10 kΩ unbalanced
Gain range -∞ to +15 dB
Operating level variable, +4 dBu/-10 dBV (switchable)
Max. input level +22 dBu
Common-mode rejection typ. 44 dB
CMRR @ 1 kHz
Audio Outputs
Main Out L/R
Type 1/4" TRS connector, unbalanced
Gain range -∞ to +15 dB
Impedance approx. 120 Ω
Max. output level +22 dBu
Mon Out
Type 1/4" TRS connector, unbalanced, mono
Impedance approx.120 Ω
Max. output level +22 dBu
Phones Output
Type 1/4" TRS connector, stereo
Minimum load impedance 100 Ω
System Specifications
Bandwidth 20 Hz - 20 kHz +/-0.2 dB
Frequency range 20 Hz - 200 kHz +0/-3 dB
Signal-to-noise ratio < -97 dB
THD 0.0025% @ +4 dB input 1 kHz gain 1
Crosstalk < -70 dB
Power Supply
Voltage
USA/Canada 120 V~, 60 Hz
Europe/U.K./Australia 230 V~, 50 Hz
Japan 100 V~, 50 - 60 Hz
General export model 120/230 V~, 50 - 60 Hz
Power consumption max. 14 W
Fuse 100 - 120 V~: T 630 mA H
200 - 240 V~: T 315 mA H
Mains connection Standard IEC connector
Dimensions/Weight
Dimensions approx. 1 3/4 x 19 x 8 1/2"
approx. 44.5 x 483 x 217 mm
Weight approx. 5.46 lbs / 2.48 kg
Shipping weight approx. 7.30 lbs / 3.32 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts,
modifications may be made from time to time to existing products without prior notice. Specifications and
appearance may differ from those listed or illustrated.
