EXPLODED VIEWS AND PARTS LISTS
3
EXPLODED VIEW - PARTS LIST
Item Part # Description
1 198163GS KIT, Cradle
2 194150GS KIT, Vibration, Mount, 45°
3 67989GS NUT, M8 Flange Serrated
4 190220GS HOUSING, Engine Adapter
5 NSP ASSY, Alternator (see page 5)
6 * NUT, Hex M8 - 1.25
7 195398GS TPHMS, M8 - 1.25 x 35
8 96796GS WASHER, M8 Flat
9 * WASHER, Lock 5/16 - M8
10 * SBHCS, 3/8-16 x 1.0 Lg.
11 47480GS HHCS, 5/16-24 x 7
12 * HHCS, M8 - 1.25 x 25
13 198165GS KIT, Handle
14 189009GS BRACKET, Muffler
15 695398 GASKET, Exhaust
16 * HHCS, M6 - 1.0 x 12 w/LW
17 189008GS MUFFLER
18 * SCREW, 5/16 - 18 x 3/4"
19 83083GS SCREEN, Spark Arrest
20 B4986GS DECAL, Ground, Green
21 194153GS KIT, Vibration Mount
22 86494GS SCREW, Wing M6 - 1.0 x 16
23 86292GS SCREW, 10 - 16 x 3/4, Self Drill
24 197424GS SHIELD, Heat
25 191190GS CAP
26 74908GS SCREW, M5-0.8 x 10, Taptite
31 196830GS DECAL, Exhaust Warning
34 195422GS COVER, RBC, Plastic w/ Cap
35 791745 KIT, Fuel Hose, w/clamps (cut to
fit)
Item Part # Description
37 56893GS CRIMPTITE, 10-24 x 1/2
40 199433GS KIT, Fuel Tank Hrdwr w/U-Clips
199284GS U-CLIPS, (Optional Accessory)
41 192980GS KIT, Valve, Fuel Tank
44 193668GS ASSY, Tank, Fuel (Includes Items
41, 50, 51, 52 & 55)
45 B4363GS CAP, Fuel Gauge
48 195373GS WIRE, Ground
50 188333GS DECAL, Gas Fill
51 194799GS DECAL, Danger
52 189235GS DECAL, Start Instructions
55 197798GS DECAL, Shut-Off, Fuel
58 197641GS ASSY, Control Panel (see page 4)
59 * NUT, Palnut, 3/16"
900 § ENGINE
Parts Not Illustrated
199408GS MANUAL, Operator’s
199384GS DECAL, Family, CA EVP
197474GS CORDSET, Storm
198166GS KIT, Decals
Optional Accessories
100031 STABILIZER, Fuel
BB3061GS BOTTLE, Oil
* - Items without part numbers are common fasteners
and are available at your local hardware store.
§ - Contact Engine Manufacturer
