UNIT PARTS
8
For Models: W8TXEGFYQ00, W8TXEGFYB00
(White) (Black)
W10423843
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 W10222450 Support Plate,
Compressor
2 489442 Screw
3 2264597 Condenser
4 2176942 Heater, Defrost
5 2264835 Clip, Condenser
6 8533859 Screw
7 2319224 Heat Shield
8 W10358308 Air Baffle
9
2188874 Motor, Condenser
10 2262191 Wedge−Evaporator
11 939054 Clip, Wire
12 Start Device
Combination
(Start Relay and
Overload)
W10197428 Production
W10128791 Service
13 Drier
W10190413 Production
2317845 Service
14 Grommet
2264447 Production
10835901 Service
15 2263920 Evaporator Assy.
16 2263990 Strap
17 2150304 Roller
18 2264756 Rivet−Axle
19 2263628 Bale, Strap
20 2264278 Tube, Drain
21 2266467 Clip, Harness
22 2174739 Tube, Process
23 2262192 Wedge, Evaporator
24 2264129 Fan Blade
25 2264841 Screw
26 2266360 Shield−Electrical
27 W10151677 Wire Assembly
Unit
28 W10200250 Compressor
(Includes Items
12, 13, 14 & 29)
(Also Order
482801
Installation Kit
& 876765
Tube Kit)
29 Capacitor
2264017 Production
2264017 Service
30 2264838 Sleeve
31 W10209727 Extension,
Tube−Heat
32 2263928 Evaporating Tray
33 W10336305 Tube, Discharge
(Incl.Pre−Cooler)
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
3.75 Ozs.
(R134A)
