8
Drying table
Cottons/Coloureds (textiles made of cotton or linen such as underwear, T-shirts, sweaters, trousers, kitchen towels)
Dry weight in kg 0,5ɛ1,0 1,0ɛ2,0 2,0ɛ3,0 3,0ɛ4,0 ɛ0,5 ɛ1,0 ɛ2,0 ɛ2,5
Estimated drying time in minutes Selectable drying time in minutes
Cupboard dry
< 60 60ɛ80 80ɛ110 110ɛ150
30 60 90 120
/ < 65 65ɛ90 90ɛ130 130ɛ160
Recommended programme Intensive Dryc(auto) Intensive Dryc(time)
Quilt/Terry towel (big or thick textiles made of cotton such as terry towels, bed sheets, table cloths, jeans, workwear)
Dry weight in kg 0,5ɛ1,0 1,0ɛ2,0 2,0ɛ3,0 3,0ɛ4,0 ɛ0,5 ɛ1,0 ɛ1,5 ɛ2,0
Estimated drying time in minutes Selectable drying time in minutes
Cupboard dry
< 60 60ɛ90 90ɛ120 120ɛ160
30 60 90 120
/ < 80 80ɛ110 110ɛ140 140ɛ170
Recommended programme Intensive Dryc(auto) Intensive Dry (time)
Easy-Care (textiles made of synthetic or mixed fibres such as shirts, sportswear, delicate garments)
Dry weight in kg 0,5ɛ1,0 1,0ɛ2,0 2,0ɛ2,5 ɛ0,5 ɛ1,0 ɛ1,5 ɛ2,0
Estimated drying time in minutes Selectable drying time in minutes
Cupboard dry
< 50 50ɛ100 100ɛ120
30 60 90 120
/ < 60 60ɛ110 110ɛ130
Recommended programme Gentle Dryc(auto) Gentle Dry (time)
L Times are approximate and refer to standard load, spin programme and environment temperature.
L The maximum selectable drying time (time dry) is 120 minutes, if the load of the laundry to be dried is more than 2.5 kg, please select
auto dry function. Auto dry is recommended to achieve good drying result and save energy. 15âminutes time dry programme is for
cooling down the laundry.
Consumption values
Programme Option Load
Electricity
consumption ***
Water ***
Programme
duration ***
Cottons 30 °C** 7 kg 0,49 kWh 74 l 2:18 h
Cottons 40 °C** 7 kg 0,57 kWh 74 l 2:18 h
Cottons Eco 60 °C** 7 kg 1,19 kWh 51 l 2:31 h
Cottons 90 °C 7 kg 2,10 kWh 84 l 2:15 h
Easy-Care 40 °C** 3,5 kg 0,48 kWh 58 l 1:00 h
Mixed Load 40 °C ** 3,5 kg 0,54 kWh 52 l 1:03 h
Delicates Silkc30 °C 2 kg 0,15 kWh 28 l 0:39 h
Wool : (cold) 2 kg 0,08 kWh 42 l 0:36 h
Wool 30 °C 2 kg 0,16 kWh 42 l 0:36 h
Intensive Dry 4 kg 2,55 kWh 3 l 2:30 h
Gentle Dry 2,5 kg 1,55 kWh 3 l 2:00 h
Fluff Clean ø: (cold) - 0,04 kWh 29 l 0:16 h
Cottons Eco 60 °C +
Intensive Dry (2 cycles)*
* 7/3,5 kg 5,67 kWh 57 l 6:58 h
* Programme setting for testing and energy labelling in accordance with EN50229, EU directive 96/60/EC..
** Programme setting for testing according to the currently valid version of EN60456.
Note for comparative testing: to test using the test programmes, wash using the specified load amount and maximum spin speed.
Select the
Mixed Load 40 °C programme and maximum spin speed as the short programme for coloureds.
*** The values deviate from the indicated values depending on water pressure, hardness, and inlet temperature, ambiente temperature,
type, amount and soiling of the laundry, detergent used, fluctuations in the power supply and selected additional functions.
9
ʑ
Display symbols
ʑ
Display information
Before starting a programme, the
max. load for the selected
programme is displayed when the
door is open.
The remaining time or finish-in
time is displayed when the door is
closed. Drying status (Auto dry
mode/Time dry duration/OFF) **
* Display shown may vary
depending on the model and
selected programme.
** Only when the drying
programme is available.
ʑ Option buttons
You can change the spin speed and temperature even while the selected programme is running.
The effects depend on the progress of the programme.
S Temp.
You can change the indicated washing temperature. The maximum washing temperature which
can be selected depends on the programme that has been chosen. a
Page 7
þ ( Washing): On if wash process is running.
c( Rinse): On if rinse process is running.
( Spin): On if spin process is active.
7( Drying) : On if drying process is active.
( Automatic load detection) : Automatically detects the
load size after water inlet phase and sets accurate remaining
time. Symbols indicate small, middle and full loads measured *
according to the recommended max. load of the selected
programme.
* Automatic display of the detected load only for washing
programmes with a max. load recommendation > 3.0 kg except
for Rinse, Spin and Drain. Different types of textiles with
different water absorption rates may influence the load display.
Flashing, tap not open or no water supply.
On, if low water pressure. This will extend the programme.
( Overdosage): Foam detected. Maybe too much detergent.
‰( Door):On if door can be opened.
# ( Childproof lock): On, if childproof lock is activated.
Flashing, if there is misoperation.
Activate/deactivate childproof lock. a Page 10
kg, *:maximum load recommendation in kg for selected
washing/drying programme. a Page 7: Programme overview
Time, e.g. *: programme remaining time, or
* Finish-in time defined by user. a Page 10
Dry, drying mode and drying time:
: Auto dry, for washing/drying without interruption.
:Auto dry mode 1, for solo drying programme.
:Auto dry mode 2, extra dry for solo drying programme.
: Drying programme is off;
* : Time dry, drying time defined manually. a Page 10:
7(Dry) button
: On if programme is in pause.
:On if door can be opened when programme was
paused.
: End of programme, or
: end of programme with the setting.
* : Set volume of signals. a Page 10
* : Information on the display. a Page 11
