BUNN ® practices continuous product research and improvement. We reserve the right to change specifications and product design without notice. Such
revisions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment.
All dimensions shown in inches.
Bunn Corporation owns all copyrights relating to materials in this publication. Please contact Bunn Corporation to request permission to reproduce any portion of this publication.
Dimensions & Specifications
Bunn-O-Matic Corporation of Canada - 280 Industrial Pkwy. S. Aurora, Ontario L4G 3T9 • 905-841-2866 • Fax 905-841-2775 • www.bunn.com
CANADA
Model Product # Volts Amps Tank Htr Total Capacity Cubic Weight Cord
Watts Watts per hour ft 3 /m 3 lbs/kg Attached
cDBcF15 (3 lower)* 28800.6000 120 12.5 1150 1500 3.8 gal/14.4 liter 6.3/.18 38 / 17.3 Yes
cDBcF15 (2 top)* 28800.6001 120 12.5 1150 1500 3.8 gal/14.4 liter 3.7/.10 30 / 13.6 Yes
cDBcF35 (3 lower)* 28800.6010 120/240 17.5 3500 3850 7.5 gal/28.4 liter 6.3/.18 38 /17.3 No
cDBc35 (2 top)* 28800.6013 120/240 17.5 3500 3850 7.5 gal/28.4 liter 4.0/.11 35 /15.9 No
cDBc35 (3 lower)* 28800.6009 120/240 17.5 3500 3850 7.5 gal/28.4 liter 6.4/.18 38 /17.3 No
cDBcF35 (2 top)* 28800.6014 120/240 17.5 3500 3850 7.5 gal/28.4 liter 3.7/.10 30 /13.6 No
*Models have a stainless steel trunk & plastic funnel.
Brewing capacity: based upon incoming water temp of 60ºF (140ºF rise) per 1/2 gallon brew time of 4 minutes.
Models listed as 120/208V or 120/240V must be connected to 208V or 240V electrical service respectively. Please refer to the installation manual.
Electrical: 120 volt, 15 amp. models require 2-wires plus ground service rated 120V, single phase, 60 Hz.
120/240 volt models require 3-wires plus ground service rated 120/240V, single phase, 60 Hz.
An internal terminal block is configured for connection to a 3-wire plus ground.
Plumbing: 20-90 psi (138-621 kPa). Machines supplied with 1 ⁄
4
" male flare fitting. Twin models supplied with 3 ⁄
8
" male flare fitting.
FCT MODELS ONLY
1.
4.1
15.66
17.72
1.03
3.46
13.5
7.94 PF
PF SHOWN
8.05 SST
8.50
5.94 1.03
18.89
16.77
(1LWR/2UPR WARMERS)
21.40
FCT MODELS ONLY
POWER CORD
(15 AMP, 120V
MACHINE ONLY)
8.8
17.72
15.66
4.1
7.94 PF
PF SHOWN
8.05 SST
3.46
13.5
1.03 13.94
16.50
1.03
4.63
16.77
(3 WARMERS RIGHT)
