Neff S51E50X1GB - Manual (Page 25)

en
25
Fresh water connection
– Connect the fresh-water connection
to the tap according to the installation
instructions with the enclosed parts.
Ensure that the fresh-water connection
is not kinked, crushed or twisted.
– When replacing the appliance, always
use a new water supply hose.
Water pressure:
at least 0.05 MPa (0.5 bar), maximum
1 MPa (10 bar). At a higher water
pressure: connect pressure-reducing valve
ahead.
Inlet rate:
minimum 10 litres/minute
Water temperature:
Note printing on the water inlet hose!
If models are marked with 25°, the water
temperature may be max. 25 °C (cold
water).
For all other models:
cold water preferred; hot water max.
temperature 60 °C.
Electrical connection
– Connect the appliance to an
alternating current only, ranging from
220 V to 240 V and 50 Hz or 60 Hz
via a correctly installed socket with
protective earth conductor. See rating
plate for required fusing 92.
– The socket must be near the appliance
and freely accessible following
installation.
If the plug is not freely accessible, an
allpole disconnector with a contact
opening of at least 3 mm must be
fitted on the installation side to satisfy
the relevant safety instructions.
– The connection may be modified by
technicians only.
– A power cord extension may be
purchased from customer service only.
– Use only a residual current operated
circuit-breaker which features
the symbol ‚. Only this extension
guarantees compliance with
the currently valid regulations.
– The appliance features a water
damage protection system. Please
note the system will not function
unless the power supply is connected.
Removing the appliance
Also observe the sequence of worksteps
here.
–
Disconnect the appliance from
the power supply.
– Turn off the water supply.
– Disconnect the waste water and fresh
water connections.
– Loosen fastening screws for the
furniture parts.
– If fitted, remove the base panel.
– Pull out the appliance, carefully pulling
the hose behind.
