11
Hardware
(actual Size Shown)
40 20 60 80 100 140 160 120
10
30 50 70 90 110 130 150 mm
Inch 1 ʵ 6 ʵ 5 ʵ 4 ʵ 3 ʵ 2 ʵ 0
0
(5) M4X20L Screw QTY.3
(9) Ø30XØ20X2t Washer QTY.1
(10) M20(Ø29X8t) Nut QTY.1
(14) M5X10L Self Tapping Screw QTY.4
(27) M6X80L Screw QTY.2
(13) Ø16XØ6X1.5t Washer QTY.1
(17) M8 Nut QTY.2
(23) M3(Ø17X5t) Hex Head Nut QTY.2
(26) M3(Ø15X11t) Lock Nut QTY.2
(28) Ø13XØ6X1t Washer QTY.2
(41) M8X38L Bolt QTY.1
(45) M5X15L Screw QTY.2
(50) M8X25L Bolt QTY.4
(54) M8X40L Bolt QTY.2
7
