Brinkmann 6330 User Manual
Page 27
26
Step 10
Attach heat shield plate and front
panel to the front of the cart frame
assembly using two M6 X 12mm
bolts with star washers.
Step 11
Attach heat shield plate to the
back of the cart frame assembly
using two M6 X 12mm bolts with
star washers.
Step 12
Place grease cup in middle of hole
in heat shield plate.
Heat Shield Plate
Grease Cup
Heat
Shield
Plate
Heat Shield Plate
