Chapter 1

1.2 Specifications

1.2.1 System Kernel

• CPU: GeodeLink Control Processor LX800 500MHz
• BIOS: Award 512KB flash memory
• South Bridge: GeodeLink Control Processor CS5535
• VGA: GeodeLink Control Processor LX800 500MHz
• Ethernet: Realtek RTL8100BL; IEEE 802.3u protocol compatible
• Watchdog Timer: W83627 watchdog timer; 1.6 second timeout period
• IDE: 1 EIDE channel supports one CompactFlash socket onboard

(Master) and one IDE interface harddrive (Slave)

1.2.2 I/O Ports

• 1 parallel port: supports EPP/ ECP modes
• 4 serial ports: RS-232 (COM1, COM2, COM3) and RS-232/422/485

(COM4)

• 1 RJ-45 Ethernet port
• 1 PS/2 port: 6-pin mini-DIN ports for keyboard and mouse
• 2 USB 2.0 Ports: compliant with USB 1.0 and 1.1.
• 1 PCI/104 slot

1.2.3 Safety and Environment

Safety
• FCC Class A
• CE certificated
• The front bezel is compliant with NEMA 4 and IP65

Note:

COM1 and COM2 only support half-duplex
(Maximum baud rate: 115.2Kbps)
