TPC-1261H User Manual 96
Appendix G Fuse Specifications
G.1 Fuse Specifications
Rating: 250 V AC, 5 A
Size: 5 x 20 mm
G.2 Fuse Replacement
Step 1: Remove the fuse cover
Step 2: Replace the damaged fuse with a new one
Step 3: Place the fuse cover back into position.
Figure G.1: Fuse Replacement
Note For your protection, the fuse is set to break if
the input voltage exceeds 33 V DC.
Warning Do NOT replace the fuse unless it is damaged.
Do NOT replace the fuse with a different rated fuse.
