594
Combination Unit
Washroom Accessories
Document No. 8620
© 2012 Bradley
P.O. Box 309, Menomonee Falls, WI 53052-0309
Phone: 800.BRADLEY (800.272.3539) Fax: 262.253.4161
bradleycorp.com
Page 2 of 2
This information is subject to change without notice.
5/3/2012
Dim. "A" Key Surface:
For Dim. "A" Top of Rough Wall
Opening
Bottom of Rough Wall
Opening
For Bottom Toilet Paper
Opening Lower Lip @ Dim. "A"
Top of 1½" grab bar (installed with
1½" clearance) to finished floor Not Applicable 37" (940mm) 18¾" (476mm) 19" (483mm)
36" (914mm) 33" (838mm) 14¾" (375mm) 15" (381mm)
Rough wall opening:
Partition-Mount: 15³⁄₈" (391mm) Wide x 18¼" (464mm) High x Partition Thickness
Dimensions
17¹⁄₈"
(435mm)
16¹⁄₈"
(410mm)
5"
(127mm)
½"
(13mm)
18"
(457mm)
6"
(152mm)
15¹⁄₈"
(384mm)
Push Flap
Door
Removable
Waste
Receptacle
Adjustable Flange Fixed
Flange
Toilet Tissue
Spindle (qty. 4)
Mounting
Holes
1" (25mm)
Typ.
³⁄₈ " to 2¾"
(10mm to 70mm)
Partition Thickness
4½"
(114mm)
1¼"
(32mm)
9"
(229mm)
20"
(508mm)
7¹⁵⁄₁₆"
(202mm)
1½"
(38mm)
Dim. "A"
to finished
floor
Grab bars must be ordered separately. To learn more about Bradley's
wide variety of grab bar configurations, visit bradleycorp.com.
4¼"
(108mm)
