CONTENTS
SECTION PAGE
1. WARRANTY …………………………………………. 3
2. INTRODUCTION…..…………………………………. …….. 4
3. ACCESSORIES / HOW TO USE THEM……...…………... 5
4. THE CONTROLS..…………………………………………… 6
5. COOKING GUIDE………………...…………………………. 7
6. RECIPES………………………………...…………………… 8 - 9
7. OPERATIONAL GUIDELINES…...……………………….. 10
8. DAILY CLEANING SCHEDULE………………………….. 11 - 12
9. REMOVABLE PARTS…….………………………………… 13
10. TROUBLESHOOTING………………………………………. 14
11. Spare Parts………………………………………... 15
BKI ROTARY OVENS ARE MANUFACTURED ACCORDING TO THE
FOLLOWING STANDARD:
BS EN 60 335-2-42: 2002
NOTICE : SAFETY CUT-OUT
For added safety all Rotary Ovens have a built in thermal cut-out to protect against over-heating
through component failure or incorrect use.
If for any reason the thermal cut-out operates, the oven will automatically shut down and should be
switched `OFF` disconnected from the mains and allowed to cool.
NOTE: THE THERMAL CUT-OUT WILL NOT RESET AUTOMATICALLY.
The oven must not be re-used until it has been checked by a Qualified electrician or BKI Appointed
Service Agent.
15
SPARE PARTS
AB24100300
Fat Drawer
AB24100800 Door Assy - Operator (c/w Handle)
AB24100900 Door Assy - Customer (Plain)
ASY045 Drive Motor Asy (Parvalux, c/w 2” Pully)
ASY112 Rotor Assy Complete - 3 spit
AT002 Basket Carrier
BA010 Basket
CA055 Calrod/Element
(900W)
CP002 Capacitor 2.5uf
CR002 Shaft Support Bearing
CT004 Element Clip (Push on)
DS003 Door
Seal
FT001 Rubber
Foot
FU010 Fuse 500mA (Motor)
H0110 Door
Hinge
KN019 Knob
(Timer)
LI016
Neon (Clear)
QT001 Quartz
Tube 1000W (Tab end)
QT010 Quartz Tube Holder (Ceramic)
SN006
Spring - Rotor Disc
ST001 Element Carrier (Customer side)
ST002 Element Carrier (Operator side)
SW001 Switch - Main (C17, 6 pole)
SW019 Switch - Rocker
TI018
Timer (120 mins)
TM011 Thermostat (Variable)
TM012 Thermostat (Hi-Limit)
VB004 V
Belt (A42)
For further information please contact sales on +44 0870 990 4242
