MegaPixel IP CamerasCamera reference | en 13
Bosch Security Systems User Manual F.01U.064.422 | V 1.0 | 2007.03
– Adjustable brightness, saturation, gamma, and sharpness
– Simultaneous delivery of full-field view and zoomed images
at video frame rate
– Electronic image rotation by 180 degrees
– On board motion detection
– Auto iris on NWC-0700 and NWC-0800
3.2 Connectors
NWC-0700, NWC-0800, and NWC-0900 have the following con-
nectors located on the rear side of the camera housing:
–
LAN connector (100 Base-T). The LAN connector also
accepts power-over-Ethernet, 48V DC over spare wires or
over data pairs. The cameras are compliant with IEEE
802.saf. The polarity is arbitrary. For a list of recom-
mended PoE switches, see "Network Switch or Routers."
– Via DC jack, accepting 9V-12V (+/-10%) DC supply,
500 mA. The center contact in the power connector is pos-
itive.
– DC-iris connector. NWC-0900 does not support auto-iris so
does not have this connector.
3.3 Housing and mounting
All camera models feature durable aluminum housing. The
ambient temperature should be maintained between 0 ºC and
40 ºC. The cameras are not to be used outdoors without appro-
priate protective enclosures. When using outdoor an enclosure
with proper protection grade shall be used. The NWC-0900 has
two lenses and requires a 3" window to avoid shading; there is
no such limitation for the other two models.
Cameras are mounted using a ¼" x 20 threaded hole at the top
and bottom of the housing.
The cameras are to be installed according to the applicable
code. The mounting means should be adequate for mounting a
½ kg (1 lb) camera.
CAUTION!
When mounting the camera, make sure the screw that goes into
the hole is short in length, 6.35 mm (¼ inch) or less, and does
not touch the camera board.
