ITEM PART NO. QTY. DESCRIPTION
15
1 02536.0000 2 Grommet .375" I.D. (1additional used with First Type Bracket)
2 20936.1000 1 Probe Kit (Includes items 3, 4 & 5)
3 01501.0000 1 Washer .164" I.D. x .375" O.D.
4 20203.0100 1 Lockwasher, Internal Tooth #8
5 00908.0000 1 Nut, Hex #8-32
6 04680.0000 1 Thermostat, Limit (Prior to Serial # SNG0005000)
23717.0001 1 Thermostat, Limit (Serial # SNG0005000 and up)
00932.0000 2 Spacer, Hex #10-32 (Serial # SNG0005000 and up)
7 20922.1003 1 Tank Heater, 3700W @ 208V
12322.1000 1 Tank Heater, 4000W @ 240V
00908.0000 4 Nut, Hex #8-32
8 12398.0002 1 Gasket, Tank Heater
9 - - - - - - - - 1 Tube Assy, Vent (First type. Not available order item 23)
26622.0001 1 Tube Assy, Vent (Second type)
10 - - - - - - - - 1 Bracket, Overflow Cup Mounting (First type. Not available order item 23)
27473.0000 1 Bracket, Overflow Cup Mounting (Second type)
11 03803.0000 1 Switch Assy, Liquid Level (Includes items 12, 13 & 14)
00946.0000 1 Nut, Hex .125" FPT
12 03633.0000 2 Gasket, Float Switch (Only 1 used in this application)
13 - - - - - - - - 3 Washer, Adjusting (DO NOT USE IN THIS APPLICATION)
14 03807.0000 1 Clip, Spring
15 - - - - - - - - 1 Overflow Cup Assy (First type. Order item 23)
22728.0000 1 Overflow Cup Assy (Second type)
00971.0000 2 Nut, Kep #10-32
16 12422.0000 1 Clamp, Hose .47"/.54" I.D.
17 - - - - - - - - 1 Tube, Silicone .312" I.D. x 21.50" (Order item 22)
18 12527.0001 1 Triac/Heat Sink Assy (Includes items 19, 20 & 21) (Brewers
with Electronic Control only)
12527.0008 1 Triac/Heat Sink Assy (Includes items 19, 20 & 21) (Brewers
with DBC only)
00971.0000 1 Nut, Keps #10-32
19 12561.0000 1 Heat Sink, Copper
20 12565.0002 1 Triac Assy, 40 AMP (Brewers with Electronic Control)
12565.0008 1 Triac Assy, 40 AMP (Brewers with DBC)
02328.0003 1 Screw, Pan Head #6-32 x .312"
01520.0000 1 Lockwasher, Split #6
21 M2522.1000 - Heat Sink Compound
22 03236.1001 - Tube, Silicone .312" I.D. x 36.0"
03236.1003 - Tube, Silicone .312" I.D. x 60.0"
03236.1002 - Tube, Silicone .312" I.D. x 120.0"
23 27461.0000 - Kit, Square Overflow Cup
TANK HEATER & OVERFLOW PROTECTION DEVICES
Includes item 8
Not Illustrated
Brewers with
Electronic Control
or DBC only
10886 092600
