Appendix C: Supported File Formats for USB Mode
Media
File
Extension
Format Remarks
Video Audio (Maximum resolution/Bit rate etc.)
Music .mp3 --
MPEG 1/2
Layer 1/ 2/
3 (MP3)
Sample Rate: 8K ~ 48KHz, Bit Rate:
32K~320Kbps
.jpg
Baseline
JPEG
MAX. Width 7680 Height 4320, 16 Mega-pixel
Support format: 444/ 422/ 420
Appendix D: PIN Information
Before connecting any external equipment, turn off all main power switches. If there is no switch, remove the
mains plug from the wall socket. Signal information for Mini D-sub 15 pin connector
Pin No. Signal name Pin No. Signal name Pin No. Signal name
1 R 6 Ground 11 NC
2 G 7 Ground 12 NC
3 B 8 Ground 13 H-sync
4 NC* 9 NC 14 V-sync
5 NC 10 Ground 15 NC
* NC = not connected
