Toshiba LX830-C - Manual (Page 44)

Display screen 54.61cm (21.5") or 58.42cm (23") LCD screen,
configured with the following resolution:
FHD, 1920 horizontal x 1080 vertical pixels
Legal Footnote (LCD)
For more information regarding LCD, please refer to the
Legal Footnotes
section.
Left side
The following figure shows the computer’s left side.
Figure 3-2 The left side of the computer
1
2
3
4
5
6
7
8
9
10
10
1. Display off button 6. Volume down button
2. AV select button 7. Memory media slot
3. Brightness up button 8. Headphone jack
4. Brightness down button 9. Microphone jack
5. Volume up button 10.Universal Serial Bus (USB 3.0) ports*
* Provided with some models.
Product appearance depends on the model you purchased.
Display off button Press this button to turn off the computer’s
display panel.
AV select button Press this button to switch the AV input mode.
Brightness up button Press this button to increase the computer’s
display panel brightness.
User's Manual 3-3
