BIONAIRE BCM1855 - Manual (Page 7)

5 6
2.Remove the tank from the base by holding the handle
and lifting straight up (see Figure 1).
3. Twist off the tank cap located on the bottom of the tank by turning
counter clockwise and fill the water tank with cool, fresh water.
Do not fill with warm water as this may cause leaking.
4. After filling the tank, replace the tank cap by firmly turning
clockwise and then replace the water tank on the base.
The tank will immediately begin to empty into the base.
5. Plug the power cord into a 120V AC electrical outlet.
OPERATING INSTRUCTIONS
1. The unit display will turn on when you plug the power cord
into the electrical outlet.
2. Once the unit is plugged in the digital display will show the current
room humidity (on the left of the display) and the last set humidity
level (on the right of the display).
3. To turn the humidifier on press the power button once. To adjust
the humidifier speed, press the MODE button. The humidifier will
start at HI then go to MEDIUM, LO and then the AUTO speeds (HI,
MEDIUM, LO). The humidifier will start in the last set speed unless
the humidifier has been unplugged.
Note: If condensation forms on your windows or walls, or your
humidity % on your display reads above 50% then turn the unit off.
When the tank runs out of water push the POWER button OFF and
unplug. Remove and refill the water tank as instructed, being sure
to follow the Daily maintenance instructions. Replace the tank into
the base.
NOTE: If moisture forms on the walls or windows, turn off
the humidifier.
SETTING THE ACCUSET, PROGRAMMABLE
HUMIDISTAT:
Follow the Pre-Operating instructions.
The programmable humidistat is designed to operate between
30% and 65% relative humidity range. The recommended setting
is between 40% and 50%.
1. To program a pre-set humidity level, press the MODE button
until the AUTO speeds are displayed, beginning with AUTO HIGH.
Choose your desired Auto speed setting.
2. Once you have chosen your Auto speed, choose your humidity
setting by pressing the HUMIDITY SET button. The HUMIDITY
SET button works in multiples of 5, beginning with lowest
setting, 30% and ending with highest setting, 65%.
Choose the appropriate setting and your AccuSet™ humidistat
is now programmed.
NOTE: When the humidity level in the room is less than the humidity
level you have programmed, the humidifier will continue to produce
moisture. Once the room pre-set humidity level is met, the humidifier
will stop producing moisture
REPLACING THE WICK FILTER
Through normal use, waterborne minerals and
sediment become trapped in the wick filter.
The harder your water, the greater the amount
of minerals in the water, and the more often
you will need to change your filter.
You will be able to monitor the life of the filter in your humidifier
by checking the Filter Check™ Indicator. When the unit is off,
the Filter Check™ Indicator will read in the OFF position. After 60
minutes of use, Filter Check™ Indicator (refer to Figure 2 for close-up
of indicator) will move from the OFF position and indicate your filter
condition. A brand new filter will register in the section reading GOOD
filter. After frequent use of your humidifier, the Filter Check™ Indicator
will let you know when the filter needs to be changed.
When the needle is in the CHANGE section, this means the
proper amount of moisture is not getting into your air due to the
excessive minerals and sediment that have become trapped on
your filter. At this point, you should replace your filter. It is important
to change your filter as indicated to obtain stated performance level.
To replace the filter, follow the steps below.
1. Be sure the humidifier is switched OFF and disconnected
from the electrical outlet.
2. Remove the tank and main housing to access the base tray.
3. Discard the old filter and follow weekly cleaning instructions.
4. Insert a new filter into the filter support in the base.
5. Replace the main housing and then the tank.
6. Repeat Operating Instruction steps.
It will take about 30 minutes for the humidifier to reach maximum
output. You can obtain a new filter by calling 1-800-788-5350 in
the USA or Canada or by visiting your nearest retailer or authorized
service center. This humidifier takes model BWF65 replacement filter.
Figure 2
Figure 3
A. Circular Filter Supports
B. Circular Extended Life Filter
C. Humidifier Base
B
C A
