Arkon TTO215 I - Manual

5. Attach TomTom ONE XL to the pedestal head (F).
Installation Instructions
1. Choose the best location on vehicle to place
the mount. Do not place mount in or near an
air bag deployment zone or where it will
obstruct view of the road.
TravelMount TM Windshield, Console, or Dash Mount for
TomTom TM ONE® XL portable GPS navigation device.
Compatible with TomTom TM ONE® XL portable navigation
device.
Installation for Console or Dash Mount (Optional)
6. Loosen the adjustment knob of the head (G)
and adjust the device as desired. Tighten knob to
secure.
Removal of Dash Mount
To remove the dash mount completely, use a
cotton swab dipped in isopropyl alcohol. Simply
peel up a corner of the dash mount adhesive and
swab under the pad while gently pulling until the
adhesive begins to release. Remove slowly. No
damage will occur from the adhesive if it has been
properly installed and removed per these
instructions. You may see a slight discoloration
between this area and other parts of your dash
due to fading caused by the sun.
1. Remove paper liner from adhesive on mount
disc and affix adhesive to the dash. Let stand (at
room temperature) for 24 hours before using.
The Mobile Mounting Specialists™
www.arkon.com
Arcadia, CA 91006 USA
Made in Taiwan
© Copyright 2007 Arkon Resources, Inc.
Consumer Hotline:
(USA) (800) 841-0884
(INT’L) (626) 254-9005
Mon-Fri. 9am-5pm, PST
2. Attach the adapter plate (A) into
the grooves on the back of the
TomTom One XL GPS device (B).
4. Adjust the angle of the arm by loosening
the adjustment knob (E). 3. Push the pedestal suction cup (C) firmly to the
windshield. Flip the lever (D) toward base to secure
the suction cup.
(E)
(C)
(D)
(A)
(C)
(D)
(B)
2. Push the pedestal suction cup (A) down
onto the disc (D). Flip the lever (B) down to
secure the suction cup. Adjust the angle of the
arm by loosening the adjustment knob (C).
(A)
(C)
(F)
(G)
TTO215 I Windshield Suction Mount for TomTom TM ONE ® XL
360 o rotate
Swivel Swivel
(B)
! Safety Precautions
Do not install Arkon products over an air bag cover or within the air bag
deployment zone. Arkon Resources, Inc. assumes no responsibility of liability
for injury or death as a result of car crashes and/or air bag deployment.
Arkon Resources, Inc. is not responsible for any damages caused to your car,
your device, or yourself due to the installation or use of the pedestal mount.
