Displaying text information 10, Operating this unit, Displaying text information – Pioneer DEH-5200SD User Manual
Page 10

! When playing back VBR (variable bit
rate)-recorded AAC files, the average bit
rate value is displayed. However, de-
pending on the software used to decode
AAC files,
VBR may be displayed.
2 Folder number indicator
Shows the folder number currently playing
when the compressed audio is playing.
3 Track number indicator
4 PLAY/PAUSE indicator
5 S.Rtrv indicator
Appears when Sound Retriever function is on.
6 Song time (progress bar)
7 Play time indicator
Playing a CD/CD-R/CD-RW
1 Insert the disc, label side up, into the disc loading
slot.
1 If a disc has already been inserted, press SRC/
OFF to select the built-in CD player.
Ejecting a CD/CD-R/CD-RW
1 Press h (eject).
Playing songs on a USB storage device
1 Open the USB connector cover.
2 Plug in the USB storage device using a USB
cable.
Stop playing a USB storage device
1 You may disconnect the USB storage device at
anytime.
Playing songs on an SD memory card
1 Remove the front panel.
2 Insert an SD memory card into the SD card slot.
Insert it with the contact surface facing down and
press the card until it clicks and completely locks.
3 Re-attach the front panel.
4 Press SRC/OFF to select SD as the source.
Playback will start.
Stop playing an SD memory card
1 Remove the front panel.
2 Press the SD memory card until it clicks.
The SD memory card is ejected.
3 Pull out the SD memory card.
4 Re-attach the front panel.
Selecting a folder
1 Push M.C. up or down.
Selecting a track
1 Push M.C. left or right.
Fast forwarding or reversing
1 Push and hold M.C. left or right.
Returning to root folder
1 Press and hold BAND/ESC.
Switching between compressed audio and CD-DA
1 Press BAND/ESC.
Notes
! When playing compressed audio, there is no
sound during fast forward or reverse.
! USB portable audio players that can be
charged via USB will be recharged when
plugged in and the ignition switch is set to
ACC or ON.
! Disconnect USB storage device from unit
when not in use.
! If plug and play is on and a USB storage de-
vice is present, depending on the type of de-
vice, the source may switch to
USB
automatically when you turn on the engine.
Please change plug and play setting as neces-
sary. Refer to
Displaying text information
Selecting the desired text information
1 Press DISP/ /SCRL.
CD TEXT discs: Play time
— : disc artist name
and
: track title
— : disc artist name and
:
disc title
— : disc title and
: track title
— :
track artist name and
: track title
— : track
title and play time
— : track title, : track artist
name and
: disc title
WMA/MP3/AAC/WAV:
: track title and play
time
— : track title and : artist name— :
track title and
: album title
— : file name and
: folder name
—play time— : artist name and
: album title
— : track title, : artist name
and
: album title
Scrolling the text information to the left
1 Press and hold DISP/ /SCRL.
Notes
! Incompatible text stored with the audio file
may not be displayed or may be displayed in-
correctly.
! Depending on the version of iTunes used to
write MP3/AAC files onto a disc, comment in-
formation may be incorrectly displayed.
Operating this unit
En
10
Section
02
