Specifications
Audio Inputs
INSTRUMENT INPUT ¼" TS connector, unbalanced
Input impedence 1 Mohms
Max. input level +9 dBu
AUX IN STEREO ¼" TRS stereo connector
Input impedence 15 kohms
Audio Outputs
Analog Line Outputs L/R ¼" TRS connector, balanced
Output impedance 2.2 kohms
Max. output level +20 dBu
HEADPHONES ¼" TRS stereo connector,
unbalanced
CONNECTOR
Max. output level
+15 dBu/100 ohms (+23 dBm)
MIDI
Type 5-pin DIN connector IN, OUT/
THRU
Digital Signal Processing
Converter 24-bit delta-sigma,
64/128 x oversampling
Dynamics A/D 104 dB @ preamp Bypass
Dynamics D/A 92 dB
Sample rate 31.250 kHz
DSP 100 Mips
Delay time max. 1,933 msecs.
Latency approx. 5 msecs.
(Line In to Line Out)
Display
Type 2-digit 7 segment LED display
Power Supply
Mains voltage
USA/Canada 120 V~, 60 Hz
UK/Australia 240 V~, 50 Hz
Europe 230 V~, 50 Hz
China/Korea 220 V~, 50/60 Hz
Japan 100 V~, 50/60 Hz
Power consumption 13 W
Mains connection external power supply unit
Dimensions/Weight
Dimensions 3 x 7 x 10.62"
(H x W x D) 78 x 180 x 270 mm
Weight approx. 1.76 lbs
approx. 0.8 kg
Please note these specifications are preliminary and conceptual in nature, and as such are subject
to change as product development progresses. This information is supplied for market research
purposes only and is not to be made public in any manner. This document is solely the property of
The MUSIC Group, or one of its subsidiaries, and must be surrendered upon request of the owner.
¼" LINE OUT balanced
left and right outputs
AC IN
MIDI IN and
MIDI OUT/THRU
TREBLE doubles as PRESENCE
when TAP is pressed and held
FOOTSWITCH jack accommodates
any non-latching footswitch,
i.e. FS112V
Preset VOLUME control
TUNER and Exit button MASTER VOLUME
CONFIGURATION Preset A…E buttons
select the bank’s presets, but also
live/studio configurations, MIDI settings,
drive intensity, cabinet models, reverb
varieties and noise gate intensity
Bank display with
clip and tuner LEDs
BANK UP/
BANK DOWN buttons
TAP determines 2nd parameter of
effects and functions
EFFECTS level also doubles as a
2nd effects parameter control
¼" Guitar INPUT
PHONES jack
AUX IN
EFFECTS selector
AUX LEVEL for
AUX IN jack
REVERB dial
Hold TAP to select
amps 17-32
BASS
MID
GAIN
VIRTUAL
AMPLIFICATION
V-AMP 3
