Specifications

Power source ............................. 14.4 V DC (10.8 V to 15.1 V

allowable)

Grounding system ................... Negative type
Current consumption ............ 18 A (at continuous power,

4

W)

Average current drawn ......... 5.2 A (4

W for one channel)

10.3 A (2

W for one channel)

Fuse ................................................ 40 A × 1
Dimensions (W × H × D) ... 245 mm × 56 mm × 200

mm

Weight .......................................... 2.1 kg (Leads for wiring not

included)

Maximum power output ....... 400 W × 1 (4

W) / 800 W × 1

(2

W)

Continuous power output ... 200 W × 1 (at 14.4 V, 4

W, 20

Hz to 240 Hz,

≦ 1% THD)

400 W × 1 (at 14.4 V, 2

W, 50

Hz,

≦ 1% THD)

Load impedance ...................... 4

W (2 W to 8 W allowable)

Frequency response ............... 10 Hz to 30 kHz (+0 dB, -3

dB)

Signal-to-noise ratio ............... 95 dB (IEC-A network)
Distortion ..................................... 0.03 % (10 W, 100 Hz)
Low pass filter:

Cut off frequency ........... 40 Hz to 240 Hz
Cut off slope ..................... -12 dB/oct

Bass boost:

Frequency .......................... 50 Hz
Level ..................................... 0 dB / 6 dB / 12 dB

Gain control:

RCA ...................................... 200 mV to 6.5 V
Speaker .............................. 0.8 V to 10 V

Maximum input level / impedance:

RCA ...................................... 6.5 V / 22 k

W

Speaker .............................. 10 V / 22 k

W

Notes

! Specifications and the design are subject to

modifications without notice.

! The average current drawn is nearly the maxi-

mum current drawn by this unit when an
audio signal is input. Use this value when
working out total current drawn by multiple
power amplifiers.
