4
Ordering Information
ITEM CODE
First, order the chassis for your application…
Pro Switching System II Chassis
RS-232, RS-530, X.21, V.35 ....................................SM900A
V.35 Only ...................................................................SM901A
…next, order one or two power supplies…
Power Supply Modules
110-VAC ....................................................................SM950A
220-VAC ............................................................SM950A-220
…then, select either a control card…
Management Control Cards
RS-232, RS-530, X.21, V.35.....................................SM902C
V.35 Only ...................................................................SM904C
…or a display card for your master chassis…
Terminal Display Cards
RS-232, RS-530, X.21, V.35.....................................SM903C
V.35 Only ...................................................................SM905C
…and cards…
Front Interface Cards
RS-232 .......................................................................SM906C
V.35.............................................................................SM907C
RS-530 .......................................................................SM908C
X.21.............................................................................SM909C
Universal Serial Cards
RS-232 (DB25)..........................................................SM930C
DB9 Serial ................................................................SM931C
DB15 Serial ..............................................................SM932C
RJ-11 (4-Wire) .........................................................SM933C
RJ-45 (8-Wire) .........................................................SM934C
ITEM CODE
For manual and contact-closure switching, order…
Manual Contact Closure Card.................................SM916C
To manage the Pro Switching System II, order…
Management Control Software..............................SM912A
For empty slots, order…
Blank Cover
for an Unused Interface Slot ...............................SM910C
for an Unused Power Supply Slot ..........................SM911C
For connecting test equipment, order…
Test Cords
for DB25.......................................................................SM917
for V.35 .........................................................................SM918
You may also want to order cable…
Category 5 Patch Cable, 100-MHz, 4-Pair,
Straight-Pinned, PVC, Beige,
10-ft. (3-m)................................................EVMSL05-0010
RS-232 Cable, 25-Conductor, 10-ft. (3-m)....ECM25C-0010
V.35 Interface Cable, 10-ft. (3-m),
Male/Male .............................................EYN450-0010-MM
You may also need…
Modular Adapter Kits
DB25 Male
↔RJ-11 Female 4- or 6-Wire..............FA024
DB25 Male ↔RJ-45 Female 8-Wire........................FA025
Specifications
Data Format: 8-bit data, 1 stop bit,
no parity
Management Controls:
Terminal control:
Send Data, Receive Data,
Serial Clock Transmit, Serial
Clock Receive, Request to
Send, Data Terminal Ready,
Data Carrier Detect, Data Set
Ready;
GUI control: Send Data, Receive
Data, Serial Clock Transmit,
Serial Clock Receive, Request
to Send, Data Terminal Ready,
Data Carrier Detect, Clear to
Send
Management Method: Via ASCII
terminal or software
Programmed Alarms:
RS-232, RS-530, V.35: Send Data,
Receive Data, Serial Clock
Transmit, Serial Clock
Receive, Request to Send,
Data Terminal Ready, Data
Carrier Detect, Data Set
Ready, Clear to Send;
X.21: Transmit Data, Receive
Data, Indicate, Control, Signal
Element Timing, Byte Timing
Protocols: Transparent
Speed: Terminal control: 1200, 2400,
4800, or 9600 bps; 19.2 kbps;
GUI control: 1200, 2400, 4800, or
9600 bps
CE Approval: Yes
Interface: SM900A: RS-232, RS-530,
X.21, V.35;
SM901A: V.35
Connectors: SM900A: (48) DB25 F,
(3) per circuit; (2) DB25 F for
monitor; (1) DB25 F for I/A test;
(1) DB25 F for control in/out;
SM901A: (48) M/34 F, (3) per
circuit; (2) DB25 F for monitor;
(1) DB25 F for I/A test;
(1) DB25 F for control in/out
Operating Environment:
Temperature: 32 to 104°F
(0 to 40°C);
Humidity: 10 to 80%
noncondensing
Power: 110/220 VAC, 60/50 Hz,
internal, with IEC 320 connector
(chassis can hold [2] front-loaded
power supply modules)
Size: 7"H (4U) x 19"W x 14"D
(17.8 x 48.3 x 35.6 cm)
Weight: SM900A: 29 lb. (13.2 kg)
fully loaded;
SM901A: 39 lb. (17.7 kg)
fully loaded
