26
Step 7
Attach the grease cup bracket onto
the back cart panel by inserting the
three tabs into the slots on the back
cart panel.
Note: When performing Step 8,
Lift grill body from front and
rear panels to avoid injury to
hands and fingers.
Step 8
With the help of a friend, place grill
body assembly on grill cart. Grill
body will rest between upper side
sections of cart. Align front edge of
grill body assembly with front edges
of cart frame legs. Secure using
four M6 X 12mm bolts. At this point,
fully tighten six bolts holding back
panel from Step 4 and four bolts
holding door bracket.
Grease Cup Bracket
Alignment
