4
Violet
Auxiliary 1 output
Black/White
Door trigger input (-)
Red
+12V Battery input
Orange
Siren output (+) 1.25A
Black
Ground
Brown
Lock output (-) 300mA
Yellow
Parking light output (+) built-in relay
White
Unlock output (-) 300mA
Pink
Ignition input (+)
Black/Yellow
Armed output (-) 300mA
1234
Jumper Cover removed
default settings pictured
Jumper Cover
Valet
LED
Shock Sensor
WIRING DIAGRAM
© 2003 DLC, INC.
64-1700, 6/03 Rev. 1
RELAY WIRING DIAGRAMS
TO STARTER
MOTOR
TO BATTERY
IGNITION
SWITCH
86
30
87
87a
85
BLACK/YELLOW
ARMED OUTPUT
PINK
IGNITION +12V
CUT
X
STARTER DISABLE
86
30
87
87a
85
VIOLET
AUX
OUTPUT
+12V
TO TRUNK
RELEASE WIRE
TRUNK RELEASE
86
30
87
87a
85
(+) DOOR
TRIGGER
BLACK/WHITE
DOOR INPUT
POSITIVE DOOR TRIGGER
