13mm ( 1 /
2
”)
548mm (21 5 / 8
”)
225mm (8 7 / 8
”)
Choose the Mounting Location
Plan your installation so that the amplifier is mounted where adequate ventilation is available.
Never mount an amplifier in the engine compartment of a vehicle!
WARNING! Before driving the mounting screws through any surface, be sure of what is behind that sur-
face. Check for gas tank, brake lines, and any vehicle wiring harness.
Installation—Amplifier Mounting
GT-42
1 2 . 6 – 1 4 . 4 V D C
B + B +
G RO U N D
G N D G N D
L R
M O N O
F RO N T S P E A K E R O U T P U T
M O N O
R E A R S P E A K E R O U T P U T
L R
O N
S A F E
S TAT U S 57mm (2 1 / 4
”)
