Bunn VP17A - Manual (Page 17)

ITEM PART NO. QTY. DESCRIPTION
17
ELECTRICAL AND OPERATING CONTROLS
1 13352.0008 1 Control Panel
02301.0000 4 Screw, Phillip Pan Head #6-32 x .625"
00973.0000 4 Nut , Keps #6-32
2 12921.0000 3 Switch Blank, BLK (One less used on two warmer brewers, two less used on three
warmer brewers.)
3 27727.0000 3 Switch ON/OFF 240V (Two less used on one warmer brewers, one less used on two
warmer brewers.)
4 27691.0001 1 Light Assembly, Green 240V
5 22295.0015 1 Label, Switch ON/OFF (One warmer brewers)
22295.0016 1 Label, Switch ON/OFF (Two warmer brewers)
22295.0017 1 Label, Switch ON/OFF (Three lower warmer brewers, left or right)
22295.0018 1 Label, Switch ON/OFF (One lower warmer and two upper warmer brewers)
6 25105.0004 1 Decal, Control Panel
7 01663.0000 1 Bushing, Snap .875" Dia
8 12698.0005 1 Bracket Assembly, Component Mounting
01347.0000 1 Screw, Truss Head #6-32 x .38"
02332.0001 1 Screw, Hex-Crimptite #6 x .25"
9 07038.0000 1 Terminal Block, 3 Pole
01315.0000 2 Screw, Truss Head #8-32 x .38"
01501.0000 2 Washer, Flat .164" I.D.
10 04314.0001 1 Thermostat Kit
02308.0000 1 Screw, Pan Head #8-32 x .38"
20762.0000 2 Screw, Binding Head #8-32 x .25"
11 07073.0001 1 Grommet, Thermostat
12 21016.0131 1 Lead, Electrical Grn/Yel 7" LG ( Ground to white pole in terminal block)
01375.0000 1 Screw, Pan Head - Brass #10-32 X .50"
01512.0000 1 Lockwasher, External Tooth #10
13 00824.0000 2 Decal, Ground
14 27705.0000 1 Terminal Lug (Includes setscrew)
01327.0000 1 Screw, Pan Head #10-32 x .38"
15 05746.0000 1 Bushing, Strain Relief
16 28004.0000 1 Switch, Toggle 250V DPST
17 25102.0001 1 Bracket, Switch Indicator
18 28355.0000 1 Harness Assy, Switch
19 27730.0000 1 Wiring Harness, Ready Light 240V
20 27732.0000 1 Wiring Harness, Main 240V (Early Models)
27732.0002 1 Wiring Harness, Main 240V (Model 17A-1)
27732.0003 1 Wiring Harness, Main 240V (Model 17A-2)
27732.0004 1 Wiring Harness, Main 240V (Model 17A-3)
Not Illustrated
Models with Tank Heater Switch only
10861.1 100407
(Continued)
