REFERENCE 5 S2 STEREO PREAMPLIFIER TUNER
*Specifications subject to change without notice
SPECIFICATIONS
Frequency Response 5 - 45kHz
Input Sensitivity 63 mV
Signal to Noise Ratio 89 dB
Input Impedance 50 K
W
Output Impedance 221
W
Maximum Output Level 8V
Tuner Specifications FM AM
Frequency Range 87.5 - 107.9 MHz 520 - 1670 kHz
Total harmonic Distortion Less than .25% Less than .3%
Frequency Response 20 - 15 kHz 20 - 15 kHz
Alternate Channel Selectivity 65 dB 30 dB
Signal to Noise Ratio 70 dB 70 dB
Antenna Input Impedance 75
W
300
W
IHF (Usable) Sensitivity 12dBf 28 dBf
Capture Ratio 2 dB -
Mono / Stereo Sensitivity 15 / 35 dBf -
User Presets 40
High Pass / Low Pass Crossover (RCA output) 80 Hz non-adjustable
Full Range output (RCA) Yes
Keypad or IR sensor connections Yes
Unbalanced (RCA) audio inputs 6
Balanced (XLR) outputs 1 full range pair
Tape loop output 1
RS-232 Controllable Yes
IR output (pass-through) 5V
AC Line Voltage 120 / 220 / 240 VAC (optional / switchable)
Control Output 10 - 12VDC @ 200mA
Dimensions in Inches Width
(Cutout Dimensions) Height
Depth
17.00 (17.12)
3.83 (3.95)
9.50 (10.62)
Shipping Weight 16 lbs
Power Consumption 30 watts maximum
Replacement Fuses AC Line - .5 Amp / 250 Volt Fast Blow
