Page 2
2
2 610 355 302
Field 115V
22
3
2 610 355 301
Armature w/Fan115V
AW
4
2 610 355 335
Switch
15
5
2 610 355 306
Cord
11
6
2 610 355 307
Strain Relief
11
7
2 610 355 342
Clamp
89
8
2 610 994 082
Nameplate "3814"
9
9
2 610 994 083
Label "Bosch"
9
11
2 610 355 310
Cable
10
13
2 610 010 824
Ball Bearing
60
14
2 610 023 268
Ball Bearing {2}
61
15
2 610 355 311
Baffle
24
16
2 610 355 297
Brush Holder
25
17
2 610 355 309
Washer
65
19
2 610 355 349
Baffle
24
20
2 610 994 505
Gear Housing
72
21
2 610 355 298
Brush Cap {2}
25
23
2 610 355 303
Screw {2}
89
28
2 610 355 343
Key
66
29
2 610 355 341
Screw {2}
89
30
2 610 355 337
Screw & Washer {9}
89
31
2 610 356 706
Nut {11}
89
32
2 610 355 323
Output Spindle
52
33
2 610 355 322
Gear
33
35
2 610 355 313
Needle Bearing
56
36
2 610 355 338
Screw
89
37
2 610 352 729
Sleeve
82
38
2 610 355 317
Gear Housing Cover
70
39
2 610 355 267
Screw
89
40
2 610 355 270
Screw
89
41
2 610 355 268
Screw
89
42
2 610 355 286
Knob
63
43
2 610 358 055
Bolt {3}
89
44
2 610 355 345
Bushing
82
45
2 610 355 344
Bushing {2}
82
46
2 610 355 347
Bumper {2}
9
47
2 610 355 284
Retaining Ring {2}
89
48
2 610 355 340
Hook
9
49
2 610 355 279
Chain
9
50
2 610 994 516
Base Assembly
88
51
2 610 355 314
Plug {2}
9
52
2 610 355 348
Roll Pin
66
53
2 610 355 321
Washer
65
54
2 610 355 331
Screw {2}
89
55
2 610 355 320
Retaining Ring
89
56
2 610 994 510
Pin
9
57
2 610 328 702
Push Nut
89
58
2 610 355 280
Roll Pin
66
59
2 610 355 265
Shaft
54
Service Notes:
60
2 610 355 315
Spindle Lock Pin
81
61
2 610 355 316
Spring
27
62
2 610 355 295
Screw
89
63
2 610 355 336
Screw {2}
89
64
2 610 357 149
Screw
89
65
2 610 355 259
Screw {4}
89
66
2 610 355 330
Washer {4}
65
67
2 610 355 278
Screw {2}
89
68
2 610 355 293
Screw {2}
89
69
2 610 355 304
Washer {4}
65
70
2 610 355 269
Washer
65
71
2 610 355 264
Washer {5}
65
72
2 610 355 263
Screw {2}
89
73
2 610 355 271
Washer {3}
65
74
2 610 355 277
Screw {2}
89
75
2 610 355 272
Nut {2}
89
76
2 610 355 290
Retaining Ring
89
77
2 610 355 274
Washer {2}
65
78
2 610 355 332
Nut {2}
89
79
2 610 355 325
Lock Washer {4}
65
80
2 610 355 324
Screw {4}
89
81
2 610 355 570
Washer {2}
65
82
2 610 345 391
Washer {2}
65
83
2 610 355 318
Washer
65
84
2 610 355 319
Washer
65
85
2 610 355 299
Grommet
9
98
2 610 355 329
Lower Guard
92
99
2 610 994 522
Cover Plate
70
101
2 610 910 022
Flange {2}
65
103
2 610 355 266
Spring
27
106
2 610 994 515
Lock
9
112
2 610 355 289
Crank Screw
9
114
2 610 994 511
Fence
9
120
2 610 995 518
Support Bracket
62
123
2 610 994 509
Clamp Plate
80
126
2 610 355 275
Plate
9
127
2 610 994 086
Label "Warning"
9
130
2 610 355 258
Post {4}
9
132
2 610 355 328
Upper Guard
92
+ 145
2 610 994 085
Label "Depth"
9
+ 146
2 610 994 084
Label "Warning"
9
150
2 610 910 023
Bolt
89
152
2 610 994 512
Side Cover
92
154
2 610 994 513
Support Bracket
62
652
2 610 355 260
Wrench
9
801
2 610 994 504
Motor Housing Assembly 71
w/pos. 16, 62, 85
810
2 610 995 539
Brush Set
26
811
2 610 995 517
Handle Assembly
74
+ = Not Illustrated * = As Required F/C = Failure Code AW = Refer to AW Labor Time Chart
F/C
Pos.
Part Number
Description {Qty}
F/C
Pos.
Part Number
Description {Qty}
3814
CHOP SAW
