Part No. 890255 Form No. F021695C Page 7 of 8
P
A
R
TS LIST 7
Item
No. Part No.
KD502H
QTY
Part No.
KD502Q
QTY QTY
Part No.
KD502ICQ
1 DEBRIS BAG (INCL. (2) OF 4,5,11) Service Assembly 900803 1 900803 1 900803 1
2 THROTTLE ASSEMBLY (INCL. 1 EACH ITEMS 4, 10) 810135 1 810135 1 810135 1
3 WASHER - FLAT FENDER (11/32 X 1 - 1/4 X 0.05) *8172020 6 *8172020 6 *8172020 6
4 NUT LOCK (1/4 - 20 NC) *8160001 4 *8160001 4 *8160001 4
5 SCREW, CAP ( 1/4 - 20 NC X 1 -1/2 HEX) *8041008 2 *8041008 2 *8041008 2
6 HANDLE ASSY (INCL. ITEMS 4(2), 5(2), 11(2), 29(2), 15, 4, 14) 900910 1 900910 1 900910 1
7 AXLE REAR - PUSH 900925 1 900925 1 900925 1
8 SCREW, CAP 5/16 NC X 1 -1/2 *8041030 2 *8041030 2 *8041030 2
9 CLAMP CABLE 1” 900813 2 900813 2 900813 2
10 SCREW, CAP 1/4 - 20 NC X 1 - 3/4 HEX *8041009 1 *8041009 1 *8041009 1
11 ROD - BAG LOOP 800178 2 800178 2 800178 2
12 CONNECTOR QUICK DISCONNECT 890176 1 890176 1 890176 1
13 LABEL EAR EYE BREATHING 890254 1 890254 1 890254 1
14 WASHER - FLAT CUT 1/4 *8171002 1 *8171002 1 *8171002 1
15 BOLT EYE 90 900913 1 900913 1 900913 1
16 GRIP 900937 1 900937 1 900937 1
17 WASHER LOCK EXT. 5/16 *8181008 5 *8181008 2 *8181008 2
18 BRACKET - HT. ADJ. 900932 1 900932 1 900932 1
19 SCREW, CAP 5/16 NFX 1” 400164 3 - - - -
20 SPRING 900136 1 900136 1 900136 1
21 TIRE - ONLY (PER ASSY) 900507 1 900507 1 900507 1
22 PIN - HAIR COTTER 900471 1 900471 1 900471 1
23 ROD HT. ADJ. PLUNGER 900978 1 900978 1 900978 1
24 BOLT - CARRIAGE, 5/16 - 18 NC X 3 - 1/2 LG *8024050 4 *8024050 4 *8024050 4
25 WASHER - FLAT 5/16 SAE *8172008 22 *8172008 22 *8172008 22
26 NUT LOCK 5/16 - 18 NC HEX *8160002 12 *8160002 12 *8160002 12
27 HANDLE STUB (R.H.) 900911 1 900911 1 9000911 1
28 PLATE - HANDLE SUPPORT 900933 1 900933 1 900933 1
29 GRIP HANDLE 400570 2 400570 2 400570 2
30 HANDLE STUB (L.H.) 900912 1 900912 1 900912 1
31 SCREW CAP 5/16-18 X 2 - 1/2 LG. - - *8041034 1 *8041034 1
32 WASHER HUB CAP 1/2 I.D. 900927 4 900927 4 900927 4
33 AXLE FRONT MECH. ASSY. ( INCL. 17, 37, 38, 45 ) 900749 1 900749 1 900749 1
34 WHEEL ASS’Y CAST (INCLUDE 21, 36) 900509 4 900509 4 900509 4
35 WASHER 0.75 “C” 900997 0-1 900997 0-1 900997 0-1
36 BRG - ONLY (PER ASSY.) 900498 2 900498 2 900498 2
37 SCREW CAP 5/16-18 X 1” *8041028 2 *8041028 2 *8041028 2
38 SPACER 0.340” I. D. X 0.330” LG. 900745 2 900745 2 900745 2
39 PLATE - BRACE REAR 900905 2 900905 2 900905 2
40 SCREW CAP 1/4-20 X 1/2 *8041002 4 *8041002 4 *8041002 4
41 SPACER 900926 6 900926 6 900926 6
42 SCREW, SELF TAPPING 10 - 24 NC X 1/2 LG. *8123086 1 *8123086 1 *8123086 1
43 NOZZLE MAIN FRAM. ASS’Y - GREEN (INCL. item (qty) 44 (1), 42 ( 1) , 55( 1), 64(1), 70(1)) 900931 1 900931 1 900931 1
44 PLUG 900146 1 900146 1 900146 1
45 PLATE QUAD ADJUSTABLE 900746 1 900746 1 900746 1
46 GASKET - - 800411 1 800411 1
47 IMPELLER ASS’Y’ (INCLUDES iTEM 49, 50, 51) 900003 - S 1 900215 -S 1 900215 - S 1
48 PARTS BAG ASS’Y (INCL item (QTY), 9 (2), 25 (2), 26 (2), 8 (2) 20 (1), 22 (1), 16 (1)
900974 1 900974 1 900974 1
49 KEY HI PRO 5/32 X 5/8 900162 1 900162 1 900162 1
50 WASHER LOCK 3/8 TWISTED TOOTH 400502 1 400502 1 400502 1
51 SCREW CAP 3/8-24 x 1" TORQUE 50 FT- LBS (68 N.m) 900154 1 900154 1 900154 1
52 HOUSING ASS’Y (INCL. 1 EA . ITEMS 13, 65, 67, 68, 69, 70) 900757 1 900757 1 900757 1
53 ENGINE 5.5 HP HONDA 900615 1 - - - -
ENGINE 5 HP BRIGGS & STRATTON "IC" QUANTUM - - 900273 1 - -
ENGINE 5 HP BRIGGS & STRATTON QUANTUM - - - - 900622 1
54 NUT LOCK 5/16 - 18 HEX *8160002 1 *8160002 3 *8160002 3
55 ROD - BUMPER 900939 1 900939 1 900939 1
56 SCREW CAP 5/16 - 18 x 1 - 1/4 LONG - - *8041029 2 *8041029 2
SCREW CAP 5/16 - 18 x 1 - 1/2 LG. *8041030 1 - - - -
57 CAP - HUB 900468 4 900468 8 900468 8
58 WASHER - FLAT 1/2 “SAE” *8172011 8 8172011 8 *8172011 8
59 PLATE BRACE HT. ADJ. KD / TKD 900756 1 900756 1 900756 1
60 CAP END 1” I.D. 800392 2 800392 2 800392 2
61 PIN - COTTER 3/32 X 3/4 *8197016 4 *8197016 4 *8197016 4
62 LABEL DANGER FLYING MATERIAL 810736 1 810736 1 810736 1
63 LABEL DO NOT FILL WHEN ENGINE IS HOT 400268 1 400268 1 400268 1
64 GUARD FOAM INSERT 900977 1 900977 1 900977 1
65 DOOR EXHAUST ASSY (incl. items 62, 66) 890148 1 890148 1 890148 1
66 SPRING DOOR EXHAUST 890142 1 890142 1 890142 1
67 SCREW CAP # 10-24 *8059135 2 *8059135 2 *8059135 2
68 NUT LOCK # 10-24 *8164005 2 *8164005 2 *8164005 2
69 WASHER # 10-24 *8171001 2 *8171001 2 *8171001 2
70 LABEL DANGER KEEP HANDS and FEET 400424 2 400424 2 400424 2
19 19 19 19 19 Description
PARTS
LIST
Denotes parts found in parts bag assembly. * Denotes standard hardware that may be purchased locally.
